| Ref | Part Number | Description |
|---|
| 1 |
BD5-8212B-00-00 |
BOX, BATTERY 1 Price: $94.99 |
| 2 |
13S-21649-00-00 |
DAMPER Price: $7.49 |
| 3 |
BD5-2162G-00-00 |
PLATE 1 Price: $6.49 |
| 4 |
90183-06069-00 |
NUT, SPRING Price: $7.49 |
| 5 |
90109-06202-00 |
BOLT Price: $3.10 |
| 6 |
90269-07008-00 |
RIVET Price: $3.60 |
| 7 |
133-82131-00-00 |
BAND, BATTERY Price: $30.99 |
| 8 |
95022-06012-00 |
BOLT, FLANGE Price: $3.55 |
| 9 |
90183-05042-00 |
NUT, SPRING Price: $1.00 |
| 10 |
BD5-2160E-02-00 |
BOX Price: $9.99 |
| 11 |
BD5-21677-00-00 |
PLATE,FITTING 3 Price: $16.49 |
| 12 |
90269-06010-00 |
RIVET Price: $8.49 |
| 13 |
BD5-2117E-00-00 |
BRACKET, TAILLIGHT Price: $68.99 |
| 14 |
90110-06172-00 |
BOLT, HEXAGON SOCKET HEAD Price: $10.49 |
| 15 |
2C0-2174Y-00-00 |
DAMPER Price: $3.85 |
| 16 |
1RC-W2470-00-00 |
ROTOR SET Price: $79.99 |
| 17 |
95022-06014-00 |
BOLT, FLANGE Price: $3.40 |
| 18 |
B90-24780-00-00 |
SEAT LOCK ASSY Price: $33.99 |
| 19 |
95702-06500-00 |
NUT, WITH WASHER Price: $2.60 |
| 20 |
BD5-2478X-00-00 |
BRACKET, SEAT LOCK Price: $6.49 |
| 21 |
90111-06059-00 |
BOLT, HEX. SOCKET BUTTON Price: $5.49 |
| 22 |
90183-050A6-00 |
NUT, SPRING This part replaces 90183-05076-00. Price: $2.95 |
| 23 |
90183-05042-00 |
NUT, SPRING Price: $1.00 |
| 24 |
BD5-21629-00-00 |
GUARD, MUD Price: $60.99 |
| 25 |
90109-06015-00 |
BOLT Price: $5.49 |
| 26 |
90387-06048-00 |
COLLAR Price: $9.49 |
| 27 |
90201-06057-00 |
WASHER, PLATE Price: $6.49 |
| 28 |
90185-06122-00 |
NUT, SELF-LOCKING Price: $10.49 |
| 29 |
3Y6-85130-02-00 |
REAR REFLECTOR ASSY Price: $30.99 |
| 30 |
95607-05200-00 |
NUT, U FLANGE This part replaces 95602-05200-00. Price: $10.49 |
| 31 |
B88-84745-00-00 |
LICENSE LIGHT UNIT ASSY Price: $254.99 |
| 32 |
90387-05067-00 |
COLLAR Price: $7.49 |
| 33 |
90480-11009-00 |
GROMMET Price: $1.20 |
| 34 |
1RC-2622H-00-00 |
WEIGHT Price: $7.49 |
| 35 |
BD5-84703-10-00 |
BRACKET Price: $140.99 |
| 36 |
449-85131-02-00 |
REFLECTOR, REAR 1 Price: $33.99 |
| 37 |
95707-05500-00 |
NUT, FLANGE Price: $9.49 |
| 38 |
90201-06057-00 |
WASHER, PLATE Price: $6.49 |
| 39 |
95604-06200-00 |
NUT, U FLANGE This part replaces 95607-06200-00. Price: $2.95 |
| 40 |
90338-07014-00 |
PLUG Price: $4.55 |
| 41 |
BD5-21613-00-00 |
STAY, FENDER 1 Price: $98.99 |
| 42 |
BD5-21614-00-00 |
STAY, FENDER 2 Price: $98.99 |
| 43 |
BD5-2161A-00-00 |
BRACKET 3 Price: $15.49 |
| 44 |
95817-06014-00 |
BOLT, FLANGE This part replaces 90105-06020-00. Price: $2.80 |
| 45 |
90464-10008-00 |
CLAMP Price: $3.80 |
| 46 |
BD5-82318-00-00 |
WIRE, SUB-LEAD Price: $27.99 |
| 47 |
90110-08199-00 |
BOLT, HEXAGON SOCKET HEAD Price: $8.49 |
| 48 |
BD5-21651-00-00 |
COVER, REAR FENDER Price: $59.99 |
| 49 |
97707-50012-00 |
SCREW, TRUSS HEAD TAPPING Price: $4.63 |
| 50 |
1RC-2465B-01-00 |
CAP, ROTOR This part replaces 1RC-2465B-00-00. Price: $4.55 |
| 51 |
90249-03002-00 |
PIN Price: $5.49 |
| 52 |
90508-09007-00 |
SPRING, TORSION Price: $2.75 |
| 53 |
93430-02001-00 |
CIRCLIP, E-TYPE Price: $9.49 |
| 54 |
3SA-24877-A0-00 |
LABEL, CAUTION Price: $5.99 |
| 55 |
3JJ-28446-A2-00 |
LABEL, CAUTION This part replaces 3JJ-28446-A1-00. Price: $4.95 |
