| Ref | Part Number | Description |
|---|
| 44 |
73451G01 |
PLASTIC BED ASSY, 40" Price: $1,352.52 |
| 46 |
73454G01 |
TAILGATE PIVOT SHAFT Price: $29.99 |
| 47 |
73460G01 |
SHOULDER BOLT, 0.875" DIA X 3/4" Price: $9.99 |
| 48 |
73455G01 |
TAILGATE CABLE Price: $56.99 |
| 49 |
N/S |
NON-SERVICEABLE PART Price: Call Us |
| 50 |
16705G2 |
PAN HEAD PHILLIPS SCREW, 1/4-20 X 5/8 Price: $2.99 |
| 51 |
73449G01 |
EXTRUSION CHANNEL Price: $73.99 |
| 52 |
16816G5 |
RATCHET RIVET, 0.187X 0.550 Price: $1.99 |
| 53 |
73448G01 |
TAILGATE, 40 INCH, PLASTIC (E-Z-GO) Price: $425.52 |
| 54 |
00415G2 |
HEX HEAD BOLT, 1/4-20 X 1 1/4 Price: $2.99 |
| 57 |
71571G01 |
CLEVIS PIN, 1/2" X 5 1/4" Price: $5.99 |
| 58 |
00571G5 |
FLAT WASHER, WIDE, 1/2" Price: $1.99 |
| 59 |
71570G01 |
ACETAL BUSHING Price: $7.99 |
| 60 |
624030 |
FLANGED BUSHING, IGUS This part replaces 70291G01. Price: $1.99 |
| 61 |
21683G1 |
COTTER PIN, 15/32" X 2 1/16" Price: $2.99 |
| 63 |
71547G02 |
CHANNEL OUTRIGGER Price: $370.99 |
| 64 |
01118G01 |
HEX HEAD BOLT, 1/4-20 X 5/8 Price: $2.99 |
| 65 |
00642G7 |
FLAT WASHER, 1/4" Price: $2.99 |
| 66 |
72339G01 |
HEAT SHIELD Price: $81.99 |
| 69 |
27612G04 |
ELECTRIC ACTUATOR, 48V Price: $1,189.99 |
| 70 |
14443G10 |
CLEVIS PIN,.50 X 3.00 Price: $14.99 |
| 71 |
14443G11 |
CLEVIS PIN, 1.88 Price: $11.99 |
| 72 |
21683G1 |
COTTER PIN, 15/32" X 2 1/16" Price: $2.99 |
| 73 |
27613G01 |
SPACER-.75O.D. X .50I.D. Price: $34.99 |
| 74 |
74054G01 |
R/B 74054G01P HARNESS, ELECTRIC DUMP Price: Call Us |
| 75 |
17618G1 |
NYLON CLAMP, 8" Price: $1.99 |
| 76 |
11845G3 |
CABLE CLIP Price: $4.99 |
| 77 |
00532G3 |
HEX NUT, 5/16-18 Price: $0.99 |
| 78 |
25976G14 |
RED WIRE ASSY, #14GA Price: $1.01 |
| 80 |
21320G4 |
CIRCUIT BREAKER, 15 AMP, 24V Price: $27.99 |
| 81 |
00150G4 |
SLOTTED SCREW, #10-24 X 1/2 Price: $2.18 |
| 82 |
00565G5 |
LOCK WASHER, #10 Price: $0.99 |
| 83 |
00526G3 |
HEX NUT, #10-24 Price: $0.99 |
| 85 |
27680G01 |
TOGGLE SWITCH, ELECTRIC DUMP Price: $36.63 |
| 86 |
27447G01 |
TOGGLE GUARD ASSY Price: $96.88 |
| 87 |
74165G02 |
CIRCUIT BREAKER MNTG BRACKET Price: $11.69 |
