FRAME - SEAT UPRIGHT [302469]
![FRAME - SEAT UPRIGHT [302469]](https://cdn.datamanager.arinet.com/image/ARCT/7bbd03d2-6e7d-4aad-8751-85c143d6ca22/Max)
Parts (8)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 648595 | OBS - B-PILLAR,SEAT UPRIGHT Price: $37.95 |
| 2 | 655641 | BOLT,HXFL,M10-1.5X60 Not Available Price: |
| 3 | 600525 | LOCK NUT, M10-1.5 Price: $2.00 |
| 6 | 647792 | OBS - CONNECTOR,FRAME,EXTRUDED Price: $44.95 |
| 7 | 655641 | BOLT,HXFL,M10-1.5X60 Not Available Price: |
| 8 | 600525 | LOCK NUT, M10-1.5 Price: $2.00 |
| 11 | 656099 | OBS - CROSSMEMBER,SKID GUARD MT-WLD Price: $59.63 |
| 12 | 655641 | BOLT,HXFL,M10-1.5X60 Not Available Price: |
