| Ref | Part Number | Description |
|---|
| 2 |
3003-597 |
Nozzle, Oil Price: $14.55 |
| 3 |
3007-416 |
Nut Price: $2.69 |
| 4 |
3004-280 |
Washer, Lock, 8MM Price: $1.67 |
| 5 |
3007-419 |
Bolt, Stud Price: $4.94 |
| 6 |
3003-503 |
Gasket, Exhaust - Non-Asbestos Price: $19.04 |
| 7 |
3005-952 |
GASKET, INTAKE MANIFOLD Price: $17.92 |
| 8 |
3007-412 |
Bolt, Stud Price: $4.82 |
| 9 |
3004-351 |
Nut Price: $2.24 |
| 10 |
3007-413 |
Bolt, Stud Price: $6.11 |
| 11 |
3003-554 |
Insulator, Intake Manifold Price: $23.53 |
| 12 |
3004-828 |
Cap, Nozzle Price: $10.95 |
| 13 |
3008-037 |
Clamp, Hose Price: $3.81 |
| 14 |
3423-204 |
Washer Price: $1.29 |
![INTAKE ASSEMBLY [81802]](https://cdn.datamanager.arinet.com/image/ARCT/1df99a71-88d1-43d2-90d4-997dfc2b14b8/Max)
