| Ref | Part Number | Description |
|---|
| 1 |
28101KGF910 |
GEAR, STARTER DRIVEN (13T/54T) Price: Call Us |
| 1 |
30310-ZY1-003 |
COIL ASSY., PULSER Price: $66.66 |
| 2 |
28102KGF910 |
SHAFT, STARTER REDUCTION Price: Call Us |
| 2 |
30400-ZY0-003 |
MODULE, IGNITION CONTROL (CDI) Price: $225.40 |
| 3 |
28110KGF910 |
GEAR COMP., STARTING CLUTCH (59T) Price: Call Us |
| 3 |
30418-ZY1-010 |
PLATE, C.D.I. Price: $23.26 |
| 4 |
30500-ZY1-013 |
COIL ASSY., IGNITION Price: $93.97 |
| 4 |
31200KTF981 |
MOTOR ASSY., STARTING Price: Call Us |
| 5 |
30506-ZW9-003 |
SUSPENSION, IGNITION COIL Price: $8.02 |
| 5 |
31201KPCD51 |
BRUSH SET A, CARBON Price: Call Us |
| 6 |
30515-ZW9-652 |
BRACKET, IGNITION COIL Price: $12.50 |
| 6 |
31202KPCD51 |
BRUSH SET B, CARBON Price: Call Us |
| 7 |
31203KPCD51 |
BRUSH HOLDER Price: Call Us |
| 7 |
32108-ZY1-010 |
BRACKET, C.D.I. Price: $18.88 |
| 8 |
31204MEW921 |
SPRING, CARBON BRUSH Price: Call Us |
| 8 |
32109-ZY1-000 |
BRACKET, CONNECTOR Price: $19.34 |
| 9 |
31205KPCD51 |
BOLT SET Price: Call Us |
| 9 |
90011-ZW9-000 |
SEE PART DETAILS - PRI; BOLT, FLANGE (6X14) (CT200) Price: $2.34 |
| 10 |
31206MEW921 |
BOLT, TERMINAL Price: Call Us |
| 10 |
90014-ZZ5-M01 |
BOLT, FLANGE (6X25) Price: $2.56 |
| 11 |
31207HP5601 |
RING Price: Call Us |
| 11 |
90018-ZW9-000 |
SCREW-WASHER (5X16) Price: $1.78 |
| 12 |
31208MEW921 |
INSULATOR Price: Call Us |
| 12 |
91501-ZY1-003 |
CLIP, ANCHOR Price: $2.76 |
| 13 |
31209MEW921 |
STOPPER, TERMINAL Price: Call Us |
| 14 |
31210MEW921 |
WASHER Price: Call Us |
| 15 |
32413KTF980 |
CABLE, STARTER BATTERY EARTH Price: Call Us |
| 16 |
90071MB0000 |
NUT-WASHER, 6MM Price: Call Us |
| 17 |
91309425003 |
O-RING, 24.4X3.1 (ARAI) Price: Call Us |
| 18 |
91320MB0000 |
O-RING Price: Call Us |
| 19 |
91540S30003 |
CLIP, HARNESS BAND (NATURAL) (151.5MM) Price: Call Us |
| 20 |
938920501208 |
SCREW-WASHER, 5X12 Price: Call Us |
