| Ref | Part Number | Description |
|---|
| 1 |
3GW-27410-20 |
FRONT FOOTREST ASSY (LEFT) Price: Call Us |
| 5 |
3GW-27420-20 |
FRONT FOOTREST ASSY (RIGHT) Price: Call Us |
| 9 |
2J2-27416-10 |
BOLT, FOOTREST Price: Call Us |
| 10 |
2J2-27414-01 |
DAMPER, FOOTREST Price: Call Us |
| 11 |
90209-12102 |
WASHER Price: Call Us |
| 12 |
90201-08043 |
WASHER, PLATE Price: Call Us |
| 13 |
90176-08068 |
NUT, CROWN Price: Call Us |
| 15 |
95807-10020 |
BOLT, FLANGE Price: Call Us |
| 16 |
3HT-27442-00 |
BRACKET 2 Price: Call Us |
| 17 |
95607-12200 |
NUT, SELF-LOCKING Price: Call Us |
| 18 |
90201-12027 |
WASHER, PLATE Price: Call Us |
| 19 |
4BR-27431-00 |
FOOTREST, REAR 1 Price: Call Us |
| 20 |
4BR-27441-00 |
FOOTREST, REAR 2 Price: Call Us |
| 22 |
90501-15001 |
SPRING, COMPRESSION Price: Call Us |
| 23 |
93501-04011 |
BALL Price: Call Us |
| 24 |
95027-06035 |
BOLT, FLANGE Price: Call Us |
| 25 |
95607-06100 |
NUT, U Price: Call Us |
| 26 |
90387-064H8 |
COLLAR Price: Call Us |
| 28 |
2J2-27111-00 |
STAND, MAIN Price: Call Us |
| 29 |
90109-102G9 |
BOLT Price: Call Us |
| 30 |
90506-45002 |
SPRING, TENSION Price: Call Us |
| 31 |
90506-29007 |
SPRING, TENSION Price: Call Us |
| 32 |
90185-10037 |
NUT, SELF-LOCKING Price: Call Us |
| 33 |
90445-42002 |
HOSE Price: Call Us |
| 34 |
90445-217G3 |
HOSE (L70) Price: Call Us |
| 35 |
2RD-27311-00 |
STAND, SIDE Price: Call Us |
| 36 |
90109-10005 |
BOLT Price: Call Us |
| 37 |
90185-10037 |
NUT, SELF-LOCKING Price: Call Us |
| 38 |
3VD-27315-00 |
LINK, SIDE STAND Price: Call Us |
| 39 |
90506-26225 |
SPRING, TENSION Price: Call Us |
| 40 |
90506-18224 |
SPRING, TENSION Price: Call Us |
| 41 |
90445-266H4 |
HOSE (L55) Price: Call Us |
| 42 |
3HT-27211-00 |
PEDAL, BRAKE Price: Call Us |
| 43 |
3H0-27212-00 |
SHAFT, BRAKE PEDAL Price: Call Us |
| 44 |
90508-40381 |
SPRING, TORSION Price: Call Us |
| 45 |
3H0-27231-00 |
ROD, BRAKE Price: Call Us |
| 46 |
90109-06468 |
BOLT Price: Call Us |
| 47 |
92907-06100 |
WASHER, SPRING Price: Call Us |
| 48 |
97007-06020 |
BOLT Price: Call Us |
| 49 |
95307-06700 |
NUT Price: Call Us |
| 50 |
90240-08067 |
PIN, CLEVIS Price: Call Us |
| 51 |
90201-08083 |
WASHER, PLATE Price: Call Us |
| 52 |
91401-20012 |
PIN, COTTER Price: Call Us |
| 53 |
90501-10245 |
SPRING, COMPRESSION Price: Call Us |
| 54 |
90249-12008 |
PIN Price: Call Us |
