| Ref | Part Number | Description |
|---|
| 1 |
80L-13621-01-00 |
GASKET, VALVE SEAT Price: $11.99 |
| 2 |
3R5-13610-00-00 |
REED VALVE ASSEMBLY Price: $213.17 |
| 3 |
3R5-13613-00-00 |
REED, VALVE Price: $49.99 |
| 4 |
2X5-13616-00-00 |
STOPPER, REED VALVE Price: $5.08 |
| 5 |
98580-03008-00 |
SCREW, PAN HEAD (98501-03008-00 Price: $3.85 |
| 6 |
92990-03100-00 |
WASHER, SPRING (92901-03100-0 Price: $9.49 |
| 7 |
38W-13565-00-00 |
JOINT, CARBURETOR Price: $34.99 |
| 8 |
90465-08028-00 |
CLAMP Price: $7.49 |
| 9 |
91317-06020-00 |
BOLT This part replaces 91316-06020-00. Price: $2.75 |
| 10 |
38W-13581-00-00 |
CHAMBER, AIR Price: $19.96 |
| 11 |
4V3-1441K-00-00 |
EMBLEM Price: $3.50 |
| 12 |
38W-14465-00-00 |
PIPE Price: $19.49 |
| 13 |
90467-20050-00 |
CLIP Price: $5.49 |
| 14 |
38W-2415F-00-00 |
STAY, CHAMBER Price: $15.68 |
| 15 |
1E6-82131-00-00 |
BAND, BATTERY Price: $30.99 |
| 16 |
95812-06010-00 |
BOLT, FLANGE This part replaces 95811-06010-00. Price: $3.20 |
| 17 |
90460-49058-00 |
CLAMP, HOSE Price: $8.49 |
| 18 |
90450-64004-00 |
HOSE CLAMP ASSY This part replaces 90460-64065-00. Price: $16.49 |
| 19 |
38W-14453-00-00 |
JOINT,AIR CLNR 1 Price: $17.99 |
| 20 |
90460-80229-00 |
CLAMP, HOSE Price: $9.99 |
| 21 |
38W-14411-00-00 |
CASE, AIR CLEANER 1 Price: $42.12 |
| 22 |
38W-14437-00-00 |
DUCT Price: $16.49 |
| 23 |
38W-14451-00-00 |
ELEMENT, AIR CLNR Price: $77.99 |
| 24 |
38W-14458-00-00 |
GUIDE, ELEMENT Price: $9.50 |
| 25 |
90122-06013-00 |
BOLT, WING Price: $7.49 |
| 26 |
90209-06096-00 |
WASHER Price: $10.49 |
| 27 |
38W-14459-00-00 |
HOLDER, GUIDE Price: $24.99 |
| 28 |
92990-05200-00 |
WASHER, PLAIN Price: $5.00 |
| 29 |
95617-05100-00 |
NUT, U This part replaces 95601-05100-00. Price: $10.49 |
| 30 |
38W-14412-01-00 |
CAP, CLEANER CASE 1 Price: $34.99 |
| 31 |
5X3-14455-00-00 |
BAND Price: $12.49 |
| 32 |
34K-14484-00-00 |
PLATE, CLEANER CASE FITTING Price: $7.99 |
| 33 |
26A-14436-00-00 |
HOOK Price: $6.99 |
| 34 |
90267-40029-00 |
RIVET, BLIND This part replaces 90267-40073-00. Price: $9.49 |
| 35 |
92990-04200-00 |
WASHER, PLAIN Price: $2.00 |
| 36 |
97313-05014-00 |
BOLT, HEXAGON Price: $6.50 |
| 37 |
38W-1441A-00-00 |
COVER, CLNR CASE 1 Price: $2.58 |
| 38 |
38W-28339-00-00 |
MOLD, LEG SHIELD Price: $6.96 |
| 39 |
90465-08028-00 |
CLAMP Price: $7.49 |
| 40 |
38W-14454-00-00 |
JOINT Price: $32.70 |
| 41 |
38W-14463-00-00 |
JOINT, AIR CLNR 2 Price: $15.99 |
| 42 |
90506-06342-00 |
SPRING, TENSION (38) Price: $3.78 |
| 43 |
97D95-06016-00 |
BOLT, HEXAGON DEEP R This part replaces 97313-06016-00. Price: $2.76 |
