| Ref | Part Number | Description |
|---|
| 2 |
90480-12808-00 |
GROMMET Price: $2.45 |
| 3 |
90387-06899-00 |
COLLAR Price: $3.50 |
| 4 |
90183-05042-00 |
NUT, SPRING This part replaces 90183-05807-00. Price: $1.00 |
| 6 |
90119-06288-00 |
BOLT, WITH WASHER This part replaces 90119-06M17-00. Price: $4.40 |
| 7 |
90109-068B2-00 |
BOLT (B9B1) Price: $0.50 |
| 9 |
90183-05042-00 |
NUT, SPRING This part replaces 90183-05807-00. Price: $1.00 |
| 10 |
97702-50016-00 |
SCREW, TAPPING Price: $2.60 |
| 11 |
90387-06899-00 |
COLLAR Price: $3.50 |
| 12 |
90110-06087-00 |
BOLT, HEXAGON SOCKET HEAD Price: $6.49 |
| 13 |
90480-12808-00 |
GROMMET Price: $2.45 |
| 14 |
90480-17007-00 |
GROMMET Price: $9.49 |
| 15 |
90387-10107-00 |
COLLAR Price: $6.49 |
| 16 |
90183-050A6-00 |
NUT, SPRING This part replaces 90183-05076-00. Price: $2.95 |
| 17 |
90480-01559-00 |
GROMMET Price: $6.49 |
| 18 |
90119-05020-00 |
BOLT, WITH WASHER Price: $10.49 |
| 19 |
B9T-F838N-00-00 |
DUCT 1 Price: $13.49 |
| 20 |
90160-05009-00 |
SCREW, ROUND TAPPI Price: $0.55 |
| 21 |
90269-06816-00 |
RIVET Price: $1.70 |
| 22 |
90183-05042-00 |
NUT, SPRING This part replaces 90183-05807-00. Price: $1.00 |
| 23 |
90160-05009-00 |
SCREW, ROUND TAPPI Price: $0.55 |
| 25 |
90183-05042-00 |
NUT, SPRING This part replaces 90183-05807-00. Price: $1.00 |
| 26 |
97702-50016-00 |
SCREW, TAPPING Price: $2.60 |
| 27 |
90387-06899-00 |
COLLAR Price: $3.50 |
| 28 |
90110-06087-00 |
BOLT, HEXAGON SOCKET HEAD Price: $6.49 |
| 29 |
90480-12808-00 |
GROMMET Price: $2.45 |
| 30 |
90480-17007-00 |
GROMMET Price: $9.49 |
| 31 |
90387-10107-00 |
COLLAR Price: $6.49 |
| 32 |
90183-050A6-00 |
NUT, SPRING This part replaces 90183-05076-00. Price: $2.95 |
| 33 |
90480-01559-00 |
GROMMET Price: $6.49 |
| 34 |
90119-05020-00 |
BOLT, WITH WASHER Price: $10.49 |
| 36 |
1TP-2118K-A2-00 |
LABEL, CAUTION This part replaces 1TP-2118K-A1-00. Price: $8.49 |
| 37 |
90111-05056-00 |
BOLT,HEX. SOCKET B Price: $2.75 |
| 38 |
90202-05180-00 |
WASHER, PLATE Price: $11.49 |
| 39 |
B9T-F838R-00-00 |
DUCT 2 Price: $13.49 |
| 40 |
90160-05009-00 |
SCREW, ROUND TAPPI Price: $0.55 |
| 41 |
90269-06816-00 |
RIVET Price: $1.70 |
| 42 |
90183-05042-00 |
NUT, SPRING This part replaces 90183-05807-00. Price: $1.00 |
| 43 |
90160-05009-00 |
SCREW, ROUND TAPPI Price: $0.55 |
| 45 |
B9T-F836K-00-00 |
PANEL, INNER 1 Price: $11.49 |
| 46 |
90183-05042-00 |
NUT, SPRING This part replaces 90183-05807-00. Price: $1.00 |
| 47 |
90183-05M02-00 |
NUT, SPRING Price: $0.50 |
| 48 |
97707-50016-00 |
SCREW, TRUSS HEAD TAPPING Price: $1.85 |
| 49 |
B9T-F137K-00-00 |
GUIDE, AIR 3 Price: $11.49 |
| 50 |
90480-01559-00 |
GROMMET Price: $6.49 |
| 52 |
1WD-F413B-01-00 |
EMBLEM This part replaces 1WD-F413B-00-00. Price: $12.49 |
| 53 |
B9T-F837N-00-00 |
GRILL, AIR INTAKE Price: $10.49 |
| 55 |
B9T-F836L-00-00 |
PANEL, INNER 2 Price: $11.49 |
| 56 |
90183-05042-00 |
NUT, SPRING This part replaces 90183-05807-00. Price: $1.00 |
| 57 |
90183-05M02-00 |
NUT, SPRING Price: $0.50 |
| 58 |
97707-50016-00 |
SCREW, TRUSS HEAD TAPPING Price: $1.85 |
| 59 |
B9T-F137L-00-00 |
GUIDE, AIR 4 Price: $11.49 |
| 60 |
90480-01559-00 |
GROMMET Price: $6.49 |
| 62 |
1WD-F413B-01-00 |
EMBLEM This part replaces 1WD-F413B-00-00. Price: $12.49 |
| 63 |
B9T-F837R-00-00 |
GRILL, AIR INTAKE Price: $10.49 |
| 64 |
B04-E449E-00-00 |
COVER, AIR CLEANER Price: $27.99 |
| 65 |
90269-07076-00 |
RIVET Price: $8.49 |
| 66 |
90269-09001-00 |
RIVET Price: $1.85 |
| 67 |
B04-F1642-00-00 |
GUARD, FLAP Price: $5.99 |
| 68 |
B04-F1533-00-00 |
STAY, FLAP Price: $7.49 |
