INSTRUMENT PANEL
Parts (13)
| Ref | Part Number | Description |
|---|---|---|
| 2 | 8FP-77746-01-00 | GROMMET Price: $18.99 |
| 3 | 4XV-2177L-01-00 | PLATE, SPRING Price: $7.49 |
| 4 | 90154-06009-00 | SCREW, BINDING Price: $3.60 |
| 5 | 90109-06220-00 | BOLT Price: $11.49 |
| 6 | 5PW-2177L-01-00 | PLATE, SPRING Price: $7.49 |
| 8 | 8HF-77319-00-00 | DAMPER 1 Price: $12.49 |
| 9 | 5PW-28386-00-00 | HEAD Price: $18.99 |
| 10 | 8HW-21757-00-00 | WASHER, SPECIAL 1 Price: $0.50 |
| 11 | 8FP-21711-00-00 | COVER, SIDE 1 Price: $91.99 |
| 12 | 8FP-21721-00-00 | COVER, SIDE 2 Price: $91.99 |
| 13 | 8FR-7717F-00-00 | TAPE 2 Price: $4.30 |
| 14 | 8FR-77151-00-00 | PAD 1 Price: $4.80 |
| 15 | 90149-06117-00 | SCREW Price: $9.49 |
