| Ref | Part Number | Description |
|---|
| 1 |
28333-300-000 |
SPRING, KICK STARTER STOPPER Price: $3.55 |
| 2 |
50600-K26-G00 |
HOLDER, R. STEP Price: $50.67 |
| 3 |
50612-KYJ-305 |
ARM, R. STEP (COO) Price: $31.38 |
| 4 |
50617-445-840 |
SPRING, R. STEP RETURN (L. SIDE) Price: $6.84 |
| 5 |
50619-MM5-000 |
PLATE, STEP SETTING Price: $9.95 |
| 6 |
50639-ML0-010 |
PIN, STEP BAR Price: $6.36 |
| 7 |
50642-KYJ-305 |
ARM, L. STEP (COO) Price: $31.38 |
| 8 |
50644-445-840 |
SPRING, L. STEP RETURN (R. SIDE) Price: $6.84 |
| 9 |
50661-KYJ-305 |
RUBBER, MAIN STEP (COO) Price: $16.73 |
| 10 |
50700-K26-G00 |
HOLDER, L. STEP Price: $43.75 |
| 11 |
50718-MN8-000 |
PLATE, PILLION STEP CLICK Price: $2.84 |
| 12 |
50720-K94-T00 |
ARM, R. PILLION STEP Price: $14.20 |
| 13 |
50730-K94-T00 |
ARM, L. PILLION STEP Price: $14.20 |
| 14 |
90115-MV9-000 |
BOLT, MAIN STEP RUBBER SETTING Price: $4.62 |
| 15 |
92501-08008-0A |
BOLT, CAP (8X8) Price: $1.29 |
| 17 |
94102-08000 |
WASHER, PLAIN (8MM) Price: $0.98 |
| 18 |
94201-16250 |
PIN, COTTER (1.6X25) This part replaces 94201-16150. Price: $1.08 |
| 19 |
94201-20150 |
PIN, COTTER (2.0X15) Price: $1.08 |
| 20 |
50603-K94-T00 |
PIN, STEP BAR JOINT Price: $5.29 |
| 21 |
95701-08030-00 |
BOLT, FLANGE (8X30) Price: $1.29 |
| 22 |
95701-08035-00 |
BOLT, FLANGE (8X35) Price: $2.40 |
