| Ref | Part Number | Description |
|---|
| 1 |
11145-HP7-A01 |
PIN, OIL GUIDE (8MM) Price: $11.07 |
| 2 |
11300-HR3-HG0 |
COVER, FR. CRANKCASE Price: $357.13 |
| 3 |
11321-HR3-HG0 |
SPACER, FR. COVER Price: $205.07 |
| 4 |
11333-HP7-A00 |
COVER, OIL FILTER Price: $46.84 |
| 5 |
11334-HN2-000 |
BOLT, VALVE SETTING Price: $6.64 |
| 6 |
11335-HN8-000 |
COLLAR, OIL FEED PIPE SETTING Price: $5.64 |
| 7 |
11336-HN2-000 |
SPRING, ORIFICE VALVE (PINK) Price: $2.31 |
| 8 |
11337-HN2-000 |
VALVE, RELIEF Price: $8.49 |
| 9 |
11337-HN8-000 |
BOLT, OIL FEED PIPE SETTING Price: $6.47 |
| 10 |
11392-HP7-A00 |
GASKET, FR. CRANKCASE SPACER Price: $21.55 |
| 11 |
15235-HN2-000 |
JOINT, SPECIAL (Honda Code 6441620) Price: $7.24 |
| 12 |
15412-HP7-A01 |
ELEMENT, OIL FILTER Price: $15.13 |
| 13 |
15414-KF0-000 |
SPRING, OIL FILTER ELEMENT SETTING Price: $5.33 |
| 14 |
15421-HR3-A60 |
SCREEN, OIL FILTER Price: $10.05 |
| 15 |
15650-HP7-A00 |
DIPSTICK, OIL Price: $10.82 |
| 16 |
15655-HN5-670 |
CAP, OIL FILLER Price: $11.93 |
| 17 |
19215-HR6-B00 |
IMPELLER, WATER PUMP Price: $25.38 |
| 18 |
19216-HR6-MF0 |
SHAFT, WATER PUMP Price: $47.84 |
| 19 |
19217-MAL-300 |
SEAL, MECHANICAL Price: $64.27 |
| 20 |
19507-HP7-A00 |
HOSE, DRAIN Price: $4.95 |
| 21 |
22710-HP7-A00 |
PIPE A, FEED Price: $19.29 |
| 22 |
22715-HP7-A00 |
PIPE B, FEED Price: $17.55 |
| 23 |
37750-KPH-701 |
SENSOR ASSY., THERMOSTAT OIL (Honda Code 8192445) Price: $61.02 |
| 25 |
90443-MB0-000 |
WASHER, SEALING (10.2MM) Price: $3.53 |
| 27 |
90545-MC0-000 |
WASHER, OIL BOLT (10.2X15X1.4) Price: $4.25 |
| 28 |
90554-KA5-680 |
WASHER, THRUST (19MM) Price: $5.49 |
| 29 |
90599-767-C10 |
WASHER, THRUST (12X23X2) Price: $3.46 |
| 30 |
91009-HF1-671 |
BEARING, RADIAL BALL (15X32X9) Price: $27.15 |
| 31 |
91022-HP7-A01 |
BEARING, NEEDLE (16X28X13) Price: $21.69 |
| 32 |
91101-PZ9-000 |
BEARING, NEEDLE (12X16X10) This part replaces 91053-719-005. Price: $10.51 |
| 33 |
91201-MV4-003 |
OIL SEAL (12X26X7) (ARAI) Price: $6.45 |
| 34 |
91301-107-000 |
O-RING (75X2.5) Price: $6.13 |
| 35 |
91301-P7X-003 |
O-RING (19.20X1.90) (NOK) Price: $3.87 |
| 36 |
91303-KF0-003 |
O-RING (14.8X2.4) (ARAI) Price: $2.02 |
| 37 |
91304-HP5-601 |
O-RING (20.6X1.9) Price: $3.71 |
| 38 |
91305-KF0-003 |
O-RING (27X2) (ARAI) Price: $3.51 |
| 39 |
91305-MG7-003 |
O-RING (5X1.7) (ARAI) Price: $3.62 |
| 40 |
91307-KF0-003 |
O-RING (18X3) (ARAI) Price: $3.35 |
| 41 |
91313-MN5-004 |
O-RING (7.8X1.9) (NOK) Price: $2.49 |
| 42 |
91314-PC9-004 |
O-RING (8.5X1.9) (NOK) This part replaces 91314-PC9-003. Price: $4.05 |
| 43 |
91315-PC9-004 |
O-RING (6X1.5) (N0K) Price: $2.02 |
| 44 |
91316-MJ8-003 |
O-RING (8.4X2.4) Price: $2.98 |
| 45 |
92800-12000 |
BOLT, DRAIN PLUG (12MM) Price: $4.05 |
| 46 |
94109-12000 |
WASHER, DRAIN PLUG (12MM) Price: $1.28 |
| 47 |
94301-08140 |
PIN, DOWEL (8X14) (Honda Code 0069310) Price: $2.35 |
| 48 |
94520-28000 |
CIRCLIP (INNER) (28MM) Price: $1.33 |
| 49 |
95002-02130 |
CLIP, TUBE (B12.5) Price: $1.20 |
| 50 |
95701-06022-00 |
BOLT, FLANGE (6X22) Price: $1.88 |
| 51 |
95701-06040-00 |
BOLT, FLANGE (6X40) BOLT, FLANGE (6X45) Price: $1.97 |
