| Ref | Part Number | Description |
|---|
| 1 |
11210MBT000 |
PAN, OIL Price: Call Us |
| 1 |
12216-ZE2-300 |
CLIP, VALVE GUIDE (Honda Code 2089597). Price: $2.36 |
| 2 |
15100MBT000 |
PUMP ASSY., OIL Price: Call Us |
| 2 |
15332-ZW9-A30 |
GUIDE, OIL (UL) Price: $11.06 |
| 3 |
15134KE8010 |
SPROCKET, OIL PUMP DRIVEN (21T) Price: Call Us |
| 3 |
19210-ZW9-A32 |
SEE PART DETAILS - PRI; IMPELLER, PUMP (UL) Price: $21.50 |
| 4 |
15140415003 |
CHAIN, OIL PUMP (52L)(DAIDO) Price: Call Us |
| 4 |
19215-ZW9-020 |
SEE PART DETAILS - PRI; HOUSING ASSY., IMPELLER This part replaces 19215-ZW9-010. Price: $66.52 |
| 5 |
15150MBT000 |
STRAINER COMP., OIL Price: Call Us |
| 5 |
19231-ZW9-000 |
COVER, IMPELLER Price: $11.60 |
| 6 |
15154MM5000 |
PACKING, OIL STRAINER Price: Call Us |
| 6 |
19232-ZW9-000 |
GASKET, IMPELLER Price: $2.94 |
| 7 |
15220MB0010 |
VALVE ASSY., RELIEF Price: Call Us |
| 7 |
19240-ZY1-C20 |
SEE PART DETAILS - PRI; HOUSING, WATER PUMP (UL) Price: $161.66 |
| 8 |
15326KBV000 |
COLLAR, 16X18X10 Price: Call Us |
| 8 |
19243-ZW9-000 |
GROMMET, WATER PUMP HOUSING Price: $8.86 |
| 9 |
15410MCJ000 |
CARTRIDGE, OIL FILTER (TOYO ROKI) Price: Call Us |
| 9 |
19251-ZW9-A30 |
TUBE, WATER (UL) Price: $58.66 |
| 10 |
19253-ZW9-000 |
RING, WATER TUBE SEAL Price: $5.24 |
| 10 |
90019MB0000 |
BOSS, OIL FILTER Price: Call Us |
| 11 |
24311-ZY1-C20 |
ROD B, SHIFT (UL) Price: $37.48 |
| 11 |
90021MM5000 |
BOLT-WASHER, 6X12 Price: Call Us |
| 12 |
24312-ZV7-000 |
JOINT, SHIFT ROD Price: $19.72 |
| 12 |
90131883000 |
BOLT, DRAIN PLUG, 12X15 Price: Call Us |
| 13 |
24320-ZW9-630 |
ROD A, SHIFT (L) Price: $34.92 |
| 13 |
91302KE8003 |
O-RING, 18X3 (ARAI) Price: Call Us |
| 14 |
24341-ZY1-C00 |
SEE PART DETAILS - PRI; ROD, PUSH Price: $27.12 |
| 14 |
91313MB0003 |
O-RING, 14.7X2.2 (ARAI) Price: Call Us |
| 15 |
41112-ZW9-C20 |
SHAFT, VERTICAL (UL) Price: $452.78 |
| 15 |
9410912000 |
WASHER, DRAIN PLUG, 12MM Price: Call Us |
| 16 |
41116-ZW9-A30 |
SLINGER, OIL (UL) Price: $15.62 |
| 16 |
9430108140 |
DOWEL PIN, 8X14 Price: Call Us |
| 17 |
41131-ZW9-000 |
GEAR, PINION Price: $67.88 |
| 17 |
957010603200 |
BOLT, FLANGE, 6X32 Price: Call Us |
| 18 |
41135-ZW9-000 |
WASHER A, THRUST BEARING Price: $9.40 |
| 18 |
957010604000 |
BOLT, FLANGE, 6X40 Price: Call Us |
| 19 |
41136-ZW9-000 |
WASHER B, THRUST BEARING Price: $9.40 |
| 19 |
41137-ZW9-000 |
WASHER C, THRUST BEARING Price: $9.40 |
| 20 |
90102-ZW9-000 |
BOLT, FLANGE (6X12) Use from Frame SN 1005249. Price: $2.90 |
| 21 |
90105-ZW9-000 |
BOLT, FLANGE (6X20) (ENGINE NO.) Price: $3.94 |
| 22 |
90122-ZW9-000 |
BOLT-WASHER (6X90) Price: $5.24 |
| 23 |
90515-ZW9-000 |
PLATE, WATER TUBE SETTING Price: $4.60 |
| 24 |
90752-ZW9-A30 |
KEY, WOODRUFF Price: $3.14 |
| 25 |
91052-ZV4-003 |
BEARING, NEEDLE (15X21X12) Price: $15.30 |
| 26 |
91251-ZW9-003 |
SEAL, WATER (15X24X5) Price: $6.54 |
| 27 |
91253-ZW9-003 |
SEAL, WATER (6MM) Price: $11.66 |
| 28 |
91301-ZG3-000 |
O-RING (42.2X2.4) (Honda Code 3621125). Price: $3.10 |
| 29 |
91351-ZW9-000 |
O-RING, WATER PUMP HOUSING Price: $9.68 |
| 30 |
94001-06490-0S |
SEE PART DETAILS - PRI; NUT, HEX. (6MM) Price: $2.82 |
| 31 |
94540-08018 |
E-RING (8MM) Price: $5.42 |
