| Ref | Part Number | Description |
|---|
| 1 |
11140-HN8-000 |
ORIFICE, MAIN Price: $12.89 |
| 2 |
11300-HN8-010 |
COVER ASSY., FR. Price: $529.29 |
| 3 |
11311-HN8-A60 |
STAY, R. FR. ENGINE SIDE COVER Price: $18.58 |
| 4 |
11321-HN8-000 |
STAY, L. FR. ENGINE SIDE COVER Price: $23.02 |
| 5 |
11332-HN8-000 |
JOINT, OIL HOSE Price: $33.82 |
| 6 |
11333-HN8-000 |
COLLAR, FR. COVER Price: $4.64 |
| 7 |
11335-HN8-000 |
COLLAR, OIL FEED PIPE SETTING Price: $5.64 |
| 8 |
11336-HN8-000 |
BOLT, OIL PASSAGE Price: $5.27 |
| 9 |
11337-HN8-000 |
BOLT, OIL FEED PIPE SETTING Price: $6.47 |
| 10 |
15411-HN8-010 |
COVER, OIL FILTER Price: $39.65 |
| 11 |
15412-KEA-003 |
ELEMENT, OIL FILTER Price: $11.33 |
| 12 |
15414-300-000 |
SEAT, OIL FILTER SPRING Price: $4.89 |
| 13 |
15415-413-000 |
SPRING, FILTER ELEMENT SETTING Price: $4.35 |
| 14 |
15420-HN2-000 |
BOLT, OIL FILTER CENTER Price: $54.93 |
| 15 |
15650-HN8-000 |
DIPSTICK, OIL Price: $16.85 |
| 16 |
22715-HN8-000 |
PIPE B, FEED Price: $26.56 |
| 17 |
22725-HN8-000 |
PIPE C, FEED Price: $28.58 |
| 19 |
90409-HN8-000 |
WASHER, THRUST (22X15.5X0.5) Price: $2.09 |
| 21 |
90601-HN8-000 |
CIRCLIP (INNER) (22MM) Price: $1.58 |
| 22 |
91012-HN2-004 |
BEARING, RADIAL BALL (6005) (NTN) Price: $18.58 |
| 23 |
91017-HN8-003 |
BEARING, RADIAL BALL SPECIAL (6303) Price: $16.42 |
| 24 |
91203-KCY-671 |
OIL SEAL (25X35X5) Price: $8.95 |
| 25 |
91301-107-000 |
O-RING (75X2.5) Price: $6.13 |
| 26 |
91301-473-003 |
O-RING (7X1.7) Price: $3.11 |
| 27 |
91301-P7X-003 |
O-RING (19.20X1.90) (NOK) Price: $3.87 |
| 28 |
91302-377-000 |
O-RING (15X2.5) (Honda Code 0386995) Price: $6.67 |
| 29 |
91302-HN8-000 |
O-RING (43X2.5) Price: $3.38 |
| 30 |
91303-HN8-003 |
O-RING (17.8X1.9) Price: $2.13 |
| 31 |
91305-KF0-003 |
O-RING (27X2) (ARAI) Price: $3.51 |
| 32 |
91305-MG7-003 |
O-RING (5X1.7) (ARAI) Price: $3.62 |
| 33 |
91314-PC9-004 |
O-RING (8.5X1.9) (NOK) This part replaces 91314-PC9-003. Price: $4.05 |
| 34 |
91315-PC9-004 |
O-RING (6X1.5) (N0K) Price: $2.02 |
| 35 |
91316-MJ8-003 |
O-RING (8.4X2.4) Price: $2.98 |
| 36 |
91305-679-003 |
O-RING (22.1X2) Price: $5.88 |
| 37 |
94301-08140 |
PIN, DOWEL (8X14) (Honda Code 0069310) Price: $2.35 |
| 38 |
95701-06025-00 |
BOLT, FLANGE (6X25) Price: $1.88 |
| 39 |
95701-06035-00 |
BOLT, FLANGE (6X35) Price: $1.97 |
| 40 |
95701-06050-00 |
BOLT, FLANGE (6X50) (Honda Code 2410975) Price: $2.27 |
