| Ref | Part Number | Description |
|---|
| 1 |
16500-Z4H-010 |
CONTROL ASSY. This part replaces 16500-Z4H-000. Price: $8.62 |
| 2 |
16551-ZE0-010 |
SEE PART DETAILS - PRI; ARM, GOVERNOR (Honda Code 1950609). Price: $15.66 |
| 3 |
16555-ZE0-000 |
ROD, GOVERNOR (Honda Code 1427301). Price: $5.90 |
| 4 |
16561-ZE0-030 |
SEE PART DETAILS - PRI; SPRING, GOVERNOR Price: $3.74 |
| 5 |
16562-ZE0-020 |
SPRING, THROTTLE RETURN (Honda Code 1961408). Price: $4.40 |
| 6 |
16571-Z4H-000 |
LEVER, CONTROL Price: $2.98 |
| 7 |
16574-ZE1-000 |
SPRING, LEVER (Honda Code 1427384). Price: $4.12 |
| 8 |
16575-ZH8-000 |
SEE PART DETAILS - PRI; WASHER, CONTROL LEVER (Honda Code 3683604). Price: $5.62 |
| 9 |
16578-ZE1-000 |
SPACER, CONTROL LEVER (Honda Code 1427400). Price: $5.38 |
| 11 |
16584-883-300 |
SPRING, CONTROL ADJUSTING Use from Engine SN 2327377. Price: $5.00 |
| 12 |
90013-883-000 |
SEE PART DETAILS - PRI; BOLT, FLANGE (6X12) (CT200) (Honda Code 0636845). Price: $1.94 |
| 14 |
90022-888-010 |
BOLT, FLANGE (6X20) (CT200) (Honda Code 0671552). Price: $3.02 |
| 15 |
90114-SA0-000 |
SEE PART DETAILS - PRI; NUT, SELF-LOCK (6MM) (Honda Code 1410182). Price: $4.02 |
| 16 |
93500-05025-0H |
SCREW, PAN (5X25) (Honda Code 0374702). Price: $0.94 |
| 17 |
94050-06000 |
SEE PART DETAILS - PRI; NUT, FLANGE (6MM) (Honda Code 0471623). Price: $0.82 |
