| Ref | Part Number | Description |
|---|
| 1 |
1XD-13971-01-00 |
PIPE, FUEL 1 Price: $96.99 |
| 2 |
90464-14004-00 |
CLAMP Price: $8.49 |
| 3 |
90480-20543-00 |
GROMMET Price: $9.49 |
| 4 |
90464-20010-00 |
CLAMP Price: $3.50 |
| 5 |
1XD-F4110-00-00 |
FUEL TANK COMP. Price: $264.99 |
| 6 |
3B4-13907-13-00 |
Fuel Pump Comp Price: $346.99 |
| 7 |
3B4-24491-00-00 |
BRACKET, FUEL PUMP Price: $22.99 |
| 8 |
1S3-24486-00-00 |
O-RING Price: $18.99 |
| 9 |
95380-06800-00 |
NUT, CROWN This part replaces 95302-06800-00. Price: $9.49 |
| 10 |
BVG-24610-00-00 |
CAP ASSY Price: $32.99 |
| 11 |
90445-09827-00 |
HOSE (L160) Price: $2.65 |
| 12 |
90467-090A2-00 |
CLIP This part replaces 90467-09006-00. Price: $4.75 |
| 13 |
90445-09826-00 |
HOSE (L85) Price: $1.45 |
| 14 |
90467-090A2-00 |
CLIP This part replaces 90467-09006-00. Price: $4.75 |
| 15 |
90480-18016-00 |
GROMMET Price: $9.49 |
| 16 |
90387-07021-00 |
COLLAR Price: $8.49 |
| 17 |
90480-01400-00 |
GROMMET Price: $14.49 |
| 18 |
90387-061V1-00 |
COLLAR (2UJ) Price: $9.49 |
| 19 |
90201-065G8-00 |
WASHER, PLATE Price: $9.49 |
| 20 |
95817-06030-00 |
BOLT,FLANGE This part replaces 95802-06030-00. Price: $4.65 |
| 21 |
1XD-F4291-00-00 |
BRACKET, FUEL TANK 1 Price: $9.49 |
| 22 |
90105-06831-00 |
BOLT, FLANGE Price: $1.55 |
| 23 |
2MB-F4181-00-00 |
DAMPER, LOCATING 1 Price: $2.80 |
| 24 |
1XD-F4157-00-00 |
STAY, FUEL TANK 1 Price: $9.99 |
| 25 |
90105-08867-00 |
BOLT, FLANGE Price: $1.95 |
| 26 |
1XD-24182-00-00 |
DAMPER, LOCATING 2 Price: $8.49 |
| 27 |
28P-24380-00-00 |
PIPE JOINT ASSY Price: $43.99 |
