| Ref | Part Number | Description |
|---|
| 1 |
42316-V45-A00 |
HOLDER, BLOWER SHAFT BEARING Price: $24.98 |
| 3 |
76728-V45-A20 |
SKID, AUGER Price: $18.42 |
| 4 |
76211-V45-A00 |
BAR, SNOW DROP Price: $17.52 |
| 6 |
76710-V45-A20ZA |
HOUSING, AUGER *R280* (POWER RED) Price: $1,240.70 |
| 7 |
76322-V45-A20 |
BLADE, SCRAPER Price: $108.40 |
| 10 |
94050-08080 |
SEE PART DETAILS - PRI; NUT, FLANGE (8MM) (Honda Code 0468447). Price: $1.18 |
| 12 |
94103-08800 |
WASHER, PLAIN (8MM) Price: $1.18 |
| 15 |
95701-08012-08 |
SEE PART DETAILS - PRI; BOLT, FLANGE (8X12) (Honda Code 2647428). Price: $2.20 |
| 16 |
96150-62050-10 |
SEE PART DETAILS - PRI; BEARING, RADIAL BALL (6205UU) Price: $43.42 |
| 18 |
72423-V45-A00 |
HOLDER, AUGER BEARING Price: $17.70 |
| 19 |
72424-V45-A00 |
SPACER, AUGER BEARING Price: $9.80 |
| 20 |
76212-V45-A00 |
BRACKET, SNOW DROP BAR Price: $13.36 |
| 21 |
76728-V45-A00 |
SKID, AUGER Price: $16.30 |
| 22 |
90220-MA5-700 |
NUT, NYLON RING (6MM) Price: $11.46 |
| 23 |
91051-V45-A00 |
BEARING, RADIAL BALL (6203-19.05) Price: $6.16 |
| 24 |
94050-08080 |
SEE PART DETAILS - PRI; NUT, FLANGE (8MM) (Honda Code 0468447). Price: $1.18 |
| 25 |
94103-08800 |
WASHER, PLAIN (8MM) Price: $1.18 |
| 26 |
95701-06012-08 |
SEE PART DETAILS - PRI; BOLT, FLANGE (6X12) Use from Engine SN 2086984. Price: $2.04 |
| 27 |
95701-08012-08 |
SEE PART DETAILS - PRI; BOLT, FLANGE (8X12) (Honda Code 2647428). Price: $2.20 |
| 28 |
95701-08016-08 |
SEE PART DETAILS - PRI; BOLT, FLANGE (8X16) (Honda Code 2374767). Price: $2.20 |
| 29 |
94050-08080 |
SEE PART DETAILS - PRI; NUT, FLANGE (8MM) (Honda Code 0468447). Price: $1.18 |
| 30 |
94103-08800 |
WASHER, PLAIN (8MM) Price: $1.18 |
