| Ref | Part Number | Description |
|---|
| 3 |
24211-ZVP-000 |
SPRING, CLICK Price: $5.22 |
| 4 |
32116-ZVP-000 |
BRACKET, HARN CLIP D Price: $5.18 |
| 5 |
35660-ZVT-911 |
SENSOR ASSY. Price: $274.24 |
| 6 |
35664-ZVP-000 |
GROMMET, SENSOR HARN Price: $12.30 |
| 11 |
40219-ZY6-033 |
WIRE, LEAD (1.5X137MM) Price: $10.76 |
| 12 |
50100-ZVT-A10ZB |
FRAME *NH565* Price: $696.16 |
| 12 |
50100-ZVT-A10ZC |
FRAME *NHB14M* Price: $696.16 |
| 14 |
50117-ZVP-000 |
PLATE, ANODE METAL Price: $4.78 |
| 15 |
50151-ZW5-000 |
MOUNT, RUBBER (UPPER) Price: $141.52 |
| 16 |
50167-ZY6-000 |
HOLDER, MOUNTING (UPPER) Price: $111.12 |
| 17 |
50168-ZY6-003 |
SEE PART DETAILS - PRI; GASKET, MOUNTING HOLDER (UPPER) Price: $17.52 |
| 18 |
50201-ZVT-A10ZA |
CASE, SWIVEL *NH565* Price: $497.26 |
| 18 |
50201-ZVT-A10ZB |
CASE *NHB14M* Price: $497.26 |
| 19 |
50211-ZZ5-000 |
LINER, SWIVEL CASE Price: $8.21 |
| 20 |
50214-ZW1-000 |
BUSH, SWIVEL CASE Price: $13.17 |
| 24 |
50301-ZVT-A10ZA |
BRACKET, R. *NH565* Price: $358.18 |
| 24 |
50301-ZVT-A10ZB |
BRACKET, R. *NHB14M* Price: $358.18 |
| 25 |
50311-ZVT-A10ZA |
BRACKET, L. *NH565* Price: $358.18 |
| 25 |
50311-ZVT-A10ZB |
BRACKET, L. *NHB14M* Price: $358.18 |
| 26 |
50381-ZVL-020 |
SHAFT, TILTING Price: $105.36 |
| 27 |
50522-ZV5-000 |
BUSH, TILT ARM Price: $7.82 |
| 28 |
50527-ZW1-010 |
BRACKET, TILTING Price: $18.92 |
| 29 |
50529-ZW1-010 |
STOPPER, TILT Price: $100.24 |
| 30 |
53238-ZW1-010 |
SEE PART DETAILS - PRI; ROD, STEERING Price: $86.82 |
| 32 |
56516-ZW1-000 |
RECEIVER, THRUST Price: $25.74 |
| 33 |
56539-ZVL-000 |
SHAFT, CYLINDER (LOWER) Price: $109.88 |
| 35 |
90101-ZX2-C00 |
BOLT-WASHER (6X16) Price: $3.90 |
| 37 |
90102-ZW9-000 |
BOLT, FLANGE (6X12) Use from Frame SN 1005249. Price: $2.90 |
| 38 |
90102-ZY6-000 |
BOLT, STUD (12X145) Price: $69.42 |
| 39 |
90105-ZVL-000 |
BOLT, STUD (10X28) Price: $6.80 |
| 40 |
90105-ZW1-000 |
BOLT (3/8-24UNF) Price: $10.24 |
| 41 |
90105-ZW9-000 |
BOLT, FLANGE (6X20) (ENGINE NO.) Price: $3.94 |
| 42 |
90106-ZY3-A00 |
BOLT, FLANGE (8X22) Price: $1.42 |
| 44 |
90110-881-000 |
BOLT, HEX. (6X14) Price: $2.90 |
| 45 |
90129-ZX2-000 |
BOLT, HEX. (12X130) Price: $22.10 |
| 47 |
90302-ZW5-003 |
NUT, FLANGE (12MM) Price: $8.42 |
| 48 |
90304-ZV5-013 |
SEE PART DETAILS - PRI; NUT, SELF-LOCK (7/8-14UNF) Price: $24.24 |
| 49 |
90306-ZW4-003 |
SEE PART DETAILS - PRI; NUT, FLANGE (10MM) Price: $5.94 |
| 50 |
90307-ZV5-003 |
NUT, SELF-LOCK (3/8-24UNF) Price: $8.86 |
| 52 |
90501-ZV5-000 |
WASHER, WAVE (40MM) Price: $10.00 |
| 53 |
90502-ZV5-000 |
WASHER, WAVE (26MM) Price: $11.94 |
| 54 |
90504-921-010 |
WASHER, PLAIN (6MM) Use from Frame SN 4800713. Price: $1.74 |
| 55 |
90504-ZV5-000 |
WASHER, THRUST (34MM) Price: $10.00 |
| 56 |
90509-ZY3-000 |
WASHER (7/8") Price: $1.62 |
| 57 |
90511-921-000 |
WASHER, PLAIN (10MM) Price: $1.18 |
| 58 |
90514-ZV4-000 |
WASHER (10MM) Price: $2.32 |
| 59 |
90552-ZV5-000 |
WASHER, PLAIN (12MM) Price: $6.40 |
| 60 |
90559-ZV5-000 |
WASHER, PLAIN (12MM) Price: $4.04 |
| 61 |
90563-ZV5-000 |
WASHER, PLAIN (10MM) Price: $3.34 |
| 62 |
90651-ZV5-000 |
CIRCLIP (OUTER) (39MM) Price: $10.76 |
| 63 |
90681-763-A01 |
CLIP, WIRE HARNESS Price: $11.04 |
| 64 |
90683-ZX2-003 |
CLIP, WIRE HARNESS Price: $7.94 |
| 65 |
90951-ZV7-010 |
SEE PART DETAILS - PRI; NIPPLE, GREASE Price: $2.60 |
| 66 |
91256-ZV5-003 |
SEE PART DETAILS - PRI; OIL SEAL (39.5X52X6) (ARAI) Price: $10.68 |
| 67 |
91560-ZV5-000 |
COLLAR, STEERING ROD Price: $4.20 |
| 70 |
94001-12490-0S |
NUT, HEX. (12MM) Price: $2.60 |
| 71 |
94305-25203 |
PIN, SPRING (2.5X20) Price: $1.88 |
| 72 |
95801-08035-09 |
BOLT, FLANGE (8X35) Price: $1.70 |
