| Ref | Part Number | Description |
|---|
| 1 |
61000-24F50-YAP |
SWINGINGARM ASSY,RR (BLACK) Price: $3,126.53 |
| 5 |
61124-33E00 |
PLATE,RR SWING ARM BRKT Price: $8.46 |
| 6 |
09125-06073 |
SCREW (6X16) Price: $2.18 |
| 7 |
61251-17E20 |
SPACER,RR SWGARM PIVOT BEARIN Price: $16.22 |
| 8 |
08211-25481 |
WASHER Price: $6.97 |
| 9 |
61262-17E11 |
SEAL,DUST This part replaces 61262-17E10. Price: $11.19 |
| 10 |
61211-16G00 |
SHAFT,RR SWINGINGARM PIVOT Price: $196.39 |
| 11 |
61214-40C31 |
NUT,RR SWGARM PIVOT BOLT Price: $61.46 |
| 12 |
09160-25070 |
WASHER (25.2X42X3.2) Price: $5.81 |
| 13 |
09159-25003 |
NUT Price: $38.79 |
| 14 |
61273-15H01 |
BUFFER,CHAIN This part replaces 61273-15H00. Price: $69.02 |
| 15 |
09116-06152 |
BOLT (6X20) Price: $2.50 |
| 16 |
09180-06306 |
SPACER (6.5X9X5) Price: $2.48 |
| 17 |
61311-15H00 |
CASE,CHAIN Price: $71.29 |
| 18 |
09139-06168 |
SCREW, CHAIN CASE Price: $3.20 |
| 19 |
61446-40F00 |
ADJUSTER, CHAIN Price: $58.30 |
| 20 |
61445-40F00 |
ADJUSTER, CHAIN Price: $58.30 |
| 21 |
09100-08287 |
BOLT (8X50) Price: $3.78 |
