| Ref | Part Number | Description |
|---|
| 1 |
12204KGB305 |
GUIDE, VALVE (O.S.) Price: Call Us |
| 1 |
28571-881-000 |
PULLEY, STARTER Price: $16.58 |
| 2 |
12220KPCD50 |
HEAD COMP., RR. CYLINDER Price: Call Us |
| 2 |
30500-881-004 |
COIL ASSY., A.C. IGNITION (NOT AVAILABLE) Price: Call Us |
| 3 |
12240KGB900 |
HOLDER COMP., RR. CAMSHAFT R. SIDE Price: Call Us |
| 3 |
30540-881-004 |
COIL ASSY., PRIMARY Price: $44.32 |
| 4 |
12245KGB611 |
HOLDER COMP., RR. CAMSHAFT L. SIDE Price: Call Us |
| 4 |
30700-881-010 |
SEE PART DETAILS - PRI; CAP ASSY., NOISE SUPPRESSOR Price: $14.40 |
| 5 |
12251KGB611 |
GASKET, CYLINDER HEAD Price: Call Us |
| 5 |
12252KGB305 |
GASKET, CYLINDER HEAD (O.S.) Price: Call Us |
| 5 |
31100-881-010ZC |
SEE PART DETAILS - PRI; FLYWHEEL *TBLACK* (BLACK) Price: $383.88 |
| 6 |
12395MAT750 |
GASKET B, CYLINDER HEAD COVER Price: Call Us |
| 6 |
31630-881-004 |
COIL ASSY., CHARGE (NOT AVAILABLE) Price: $41.44 |
| 7 |
16211KPCD50 |
INSULATOR, THROTTLE BODY Price: Call Us |
| 7 |
90016-920-000 |
BOLT, FLANGE (6X12) Price: $2.46 |
| 8 |
16217MBE000 |
BAND C, INSULATOR Price: Call Us |
| 8 |
90123-881-000 |
BOLT, FLANGE (6X28) Price: $1.74 |
| 9 |
16222MV4300 |
NUT, SQUARE, 5MM Price: Call Us |
| 9 |
90124-881-000 |
BOLT, FLANGE (6X35) Price: $2.62 |
| 10 |
90201-881-000 |
NUT, SPECIAL (14MM) Price: $7.08 |
| 11 |
90002PR3000 |
BOLT, FLANGE, 6X55 Price: Call Us |
| 11 |
90742-881-000 |
SEE PART DETAILS - SUP; COLLAR, DISTANCE Price: Call Us |
| 12 |
90202KGB610 |
NUT, FLANGE, 8MM Price: Call Us |
| 12 |
91404-881-000 |
SEE PART DETAILS - PRI; CLIP, WIRE Price: $11.32 |
| 13 |
90701KK0000 |
DOWEL PIN, 8X17.5 Price: Call Us |
| 13 |
93500-06012 |
SEE PART DETAILS - SUP; SCREW, PAN (6X12) Price: $0.72 |
| 13 |
93500-06012-0A |
SEE PART DETAILS - PRI; SCREW, PAN (6X12) Price: $1.24 |
| 14 |
92900080250E |
BOLT, STUD, 8X25 Price: Call Us |
| 14 |
93500-06025-0A |
SEE PART DETAILS - PRI; SCREW, PAN (6X25) This part replaces 93500-06025. Price: $1.50 |
| 15 |
93500-06050-0B |
SCREW, PAN (6X50) Price: $1.16 |
| 15 |
93500050220G |
SCREW, PAN, 5X22 Price: Call Us |
| 16 |
94001-05330-0S |
NUT, HEX. (5MM) Price: $1.16 |
| 16 |
9405006000 |
NUT, FLANGE, 6MM Price: Call Us |
| 17 |
94001-06020-0S |
SEE PART DETAILS - PRI; NUT, HEX. (6MM) Price: $1.72 |
| 17 |
9430108140 |
DOWEL PIN, 8X14 Price: Call Us |
| 18 |
9430110160 |
DOWEL PIN, 10X16 Price: Call Us |
| 19 |
9805958916 |
PLUG, SPARK (CR8EH9)(NGK) Price: Call Us |
| 19 |
9805958926 |
PLUG, SPARK (U24FER9)(DENSO) Price: Call Us |
