EXHAUST - SEAT HEAT SHIELD [302506]
![EXHAUST - SEAT HEAT SHIELD [302506]](https://cdn.datamanager.arinet.com/image/ARCT/11f49262-2e56-4c67-b256-982e376f502f/Max)
Parts (6)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 660711G0390 | OBS-HEAT SHIELD,SEAT,BLACK This part replaces 660711. Price: $20.28 |
| 2 | 658517G01 | OBS-COVER,SEAT BELT ANCHOR,LH Price: $33.95 |
| 3 | 658517G2390 | COVER,SEAT BELT ANCHOR,RH,BLACK This part replaces 658517G02. Price: $33.95 |
| 4 | 606261 | FLANGED HEX HEAD BOLT, M8-1.25X20 Price: $0.99 |
| 5 | 645956 | FLANGED HEX NUT, M8-1.25 Price: $0.35 |
| 6 | 601476 | LOCK NUT M6-1 Price: $1.07 |
