| Ref | Part Number | Description |
|---|
| 2 |
29U-23110-00-00 |
INNER TUBE 1 Price: $160.99 |
| 3 |
29U-23170-00-00 |
CYLINDER,FRT FORK Price: $35.99 |
| 5 |
93110-30013-00 |
OIL SEAL,SWO-TYPE Price: $29.99 |
| 6 |
93450-43072-00 |
CIRCLIP,INNER Price: $10.49 |
| 7 |
29U-23141-00-00 |
SPRING,FRONT FORK Price: $22.72 |
| 8 |
5H5-23111-00-00 |
BOLT,CAP Price: $19.49 |
| 9 |
93210-21001-00 |
O-RING This part replaces 93210-21276-00. Price: $6.49 |
| 10 |
93450-27071-00 |
CIRCLIP,INNER Price: $8.49 |
| 11 |
5H5-23154-00-00 |
PLUG,INNER TUBE Price: $11.99 |
| 12 |
5H5-23173-00-00 |
SPINDLE,TAPER Price: $22.99 |
| 13 |
90430-08143-00 |
GASKET This part replaces 90430-08155-00. Price: $3.35 |
| 14 |
91314-08025-00 |
BOLT, HEXAGON SOCKET HEAD This part replaces 91311-08025-00. Price: $9.49 |
| 15 |
29U-2312A-00-00 |
BOOT Price: $39.99 |
| 16 |
90460-52259-00 |
CLAMP,HOSE Price: $5.00 |
| 17 |
90460-35260-00 |
CLAMP,HOSE Price: $4.88 |
| 18 |
98517-04020-00 |
SCREW, PAN HEAD This part replaces 98506-04020-00. Price: $9.49 |
| 20 |
29U-23110-00-00 |
INNER TUBE 1 Price: $160.99 |
| 21 |
29U-23170-00-00 |
CYLINDER,FRT FORK Price: $35.99 |
| 23 |
93110-30013-00 |
OIL SEAL,SWO-TYPE Price: $29.99 |
| 24 |
93450-43072-00 |
CIRCLIP,INNER Price: $10.49 |
| 25 |
29U-23141-00-00 |
SPRING,FRONT FORK Price: $22.72 |
| 26 |
5H5-23111-00-00 |
BOLT,CAP Price: $19.49 |
| 27 |
93210-21001-00 |
O-RING This part replaces 93210-21276-00. Price: $6.49 |
| 28 |
93450-27071-00 |
CIRCLIP,INNER Price: $8.49 |
| 29 |
5H5-23154-00-00 |
PLUG,INNER TUBE Price: $11.99 |
| 30 |
5H5-23173-00-00 |
SPINDLE,TAPER Price: $22.99 |
| 31 |
90430-08143-00 |
GASKET This part replaces 90430-08155-00. Price: $3.35 |
| 32 |
91314-08025-00 |
BOLT, HEXAGON SOCKET HEAD This part replaces 91311-08025-00. Price: $9.49 |
| 33 |
29U-2312A-00-00 |
BOOT Price: $39.99 |
| 34 |
90460-52259-00 |
CLAMP,HOSE Price: $5.00 |
| 35 |
90460-35260-00 |
CLAMP,HOSE Price: $4.88 |
| 36 |
98517-04020-00 |
SCREW, PAN HEAD This part replaces 98506-04020-00. Price: $9.49 |
| 37 |
29U-23340-10-00 |
UNDER BRACKET Price: $357.99 |
| 38 |
97070-10035-00 |
BOLT,WITH WASHER This part replaces 97023-10035-00. Price: $16.49 |
