| Ref | Part Number | Description |
|---|
| 1 |
2S3-12450-00-00 |
IMPELLER SHAFT ASSY Price: $79.99 |
| 2 |
90201-08067-00 |
WASHER, PLATE Price: $9.49 |
| 3 |
2S3-12459-00-00 |
GEAR, IMPELLER SHAFT Price: $19.49 |
| 4 |
93603-16219-00 |
PIN, DOWEL Price: $9.49 |
| 5 |
93306-00105-00 |
BEARING (B6001) Price: $33.99 |
| 6 |
93102-12106-00 |
OIL SEAL (SD 12-22-5 HS) Price: $12.49 |
| 7 |
5VK-12438-00-00 |
SEAL, MECHANICAL Price: $66.99 |
| 8 |
99009-12400-00 |
CIRCLIP Price: $3.59 |
| 9 |
93440-07182-00 |
CIRCLIP Price: $4.10 |
| 10 |
90201-12541-00 |
WASHER, PLATE Price: $8.49 |
| 11 |
2S3-12422-10-00 |
COVER, HOUSING Price: $111.99 |
| 12 |
2S3-12414-00-00 |
GASKET, COVER Price: $19.99 |
| 13 |
91314-06020-00 |
BOLT, HEXAGON SOCKET HEAD This part replaces 90110-06274-00. Price: $2.65 |
| 14 |
2S3-12483-00-00 |
PIPE 3 Price: $65.99 |
| 15 |
93210-27778-00 |
O-RING This part replaces 93210-27194-00. Price: $9.49 |
| 16 |
91314-06016-00 |
BOLT, HEXAGON SOCKET HEAD This part replaces 90110-06247-00. Price: $9.49 |
| 17 |
2S3-12485-00-00 |
PIPE 5 Price: $41.99 |
| 18 |
93210-14579-00 |
O-RING This part replaces 93210-14104-00. Price: $7.49 |
| 19 |
91314-06016-00 |
BOLT, HEXAGON SOCKET HEAD This part replaces 90110-06247-00. Price: $9.49 |
| 20 |
2S3-12481-00-00 |
PIPE 1 Price: $122.99 |
| 21 |
93210-15566-00 |
O-RING This part replaces 93210-15414-00. Price: $8.49 |
| 22 |
91312-06016-00 |
BOLT, HEXAGON SOCKET HEAD Price: $6.49 |
| 23 |
2S3-12482-00-00 |
PIPE 2 Price: $121.99 |
| 24 |
93210-15566-00 |
O-RING This part replaces 93210-15414-00. Price: $8.49 |
| 25 |
91312-06016-00 |
BOLT, HEXAGON SOCKET HEAD Price: $6.49 |
| 26 |
2S3-12589-00-00 |
HOSE 6 Price: $7.99 |
| 27 |
90450-28001-00 |
HOSE CLAMP ASSY This part replaces 90450-28014-00. Price: $16.49 |
| 28 |
2S3-12484-00-00 |
PIPE 4 Price: $44.99 |
| 29 |
2S3-12551-00-00 |
HOSE 7 Price: $15.49 |
| 30 |
90450-28001-00 |
HOSE CLAMP ASSY This part replaces 90450-28014-00. Price: $16.49 |
| 31 |
90450-32015-00 |
HOSE CLAMP ASSY Price: $19.49 |
| 32 |
2S3-1243E-00-00 |
HOSE 2 Price: $33.99 |
| 33 |
90450-28001-00 |
HOSE CLAMP ASSY This part replaces 90450-28014-00. Price: $16.49 |
| 34 |
90450-32015-00 |
HOSE CLAMP ASSY Price: $19.49 |
| 35 |
2S3-12417-00-00 |
HOUSING, THERMOSTAT Price: $39.99 |
| 36 |
5LP-12411-01-00 |
THERMOSTAT This part replaces 5LP-12411-00-00. Price: $42.99 |
| 37 |
93210-49046-00 |
O-RING Price: $8.49 |
| 38 |
95702-06500-00 |
NUT, WITH WASHER Price: $2.60 |
| 39 |
2S3-12615-00-00 |
BOLT Price: $17.49 |
| 40 |
2S3-12591-00-00 |
SUPPORT, FILLER NECK Price: $71.99 |
| 41 |
5SL-12462-01-00 |
CAP, RADIATOR This part replaces 5SL-12462-00-00. Price: $35.99 |
| 42 |
2S3-12443-00-00 |
STAY Price: $29.99 |
| 43 |
95022-06012-00 |
BOLT, FLANGE This part replaces 90105-06081-00. Price: $3.55 |
| 44 |
92014-06014-00 |
BOLT, BUTTON HEAD This part replaces 90111-06054-00. Price: $4.05 |
| 45 |
90450-22M14-00 |
HOSE CLAMP ASSY This part replaces 90450-25037-00. Price: $16.99 |
| 46 |
90450-18M09-00 |
HOSE CLAMP ASSY This part replaces 90450-22001-00. Price: $11.49 |
| 47 |
2S3-12588-00-00 |
HOSE 5 Price: $35.99 |
