| Ref | Part Number | Description |
|---|
| 5 |
50130027000 |
DOWEL 19 X15,1X12 Price: Call Us |
| 6 |
51030026100 |
DOWEL 17 X 13 X 12 Price: Call Us |
| 7 |
50130010000 |
CRANK CASE BUSH Price: Call Us |
| 9 |
58033097000 |
NEEDLE BEARING HK 2216 Price: Call Us |
| 10 |
58330011000 |
SHIFT MECHANISM SUPPORT LC4'94 Price: Call Us |
| 11 |
49030090100 |
DOWEL 9,8 X7X10 This part replaces 49030090000. Price: Call Us |
| 15 |
56530017000 |
RETAINING PLATE Price: Call Us |
| 16 |
010642060166S |
Hex screw ISO10642-M6x16 self- This part replaces 0991060166. Price: Call Us |
| 18 |
0025080166 |
HH COLLAR SCREW M8X16 TX40 This part replaces 0015080163. Price: Call Us |
| 19 |
0603082121 |
SEAL RING CU DIN7603- 8X12X1 Price: Call Us |
| 20 |
58530039400 |
ENGINE CASE SIL C4302 0,5 This part replaces 58530039300. Price: Call Us |
| 21 |
0985050103 |
OVAL HEAD SCR. DIN7985-M 5X10 Price: Call Us |
| 23 |
0412174012 |
CYLIND.ROLL.NJ 203 ECP/C3 2001 Price: Call Us |
| 24 |
0625618050 |
BALL BEARING 61805 C3 Price: Call Us |
| 26 |
60030064070 |
OIL JET 70 M6X0,75 WS8 03 Price: Call Us |
| 27 |
49030029000 |
OIL DRAIN PLUG M10X1,5 AH-WS=6 Price: Call Us |
| 28 |
49130450050 |
TUBE LW 3 Price: Call Us |
| 31 |
58530025000 |
CLUTCH COVER GASKET 2001 Price: Call Us |
| 33 |
79430020033 |
Oil filler cap cmpl. M24x3 This part replaces 58030020000. Price: Call Us |
| 34 |
0770191015 |
O-RING 19,00X3,00 NBR Price: Call Us |
| 35 |
61030019050 |
CIRCLIP OIL LEVEL GLASS 03 Price: Call Us |
| 36 |
59030019200 |
OIL SIGHT GLASS This part replaces 59030019000. Price: Call Us |
| 38 |
58333041000 |
BUMP RUBBER Not Available Price: |
| 39 |
58030047615 |
CHAIN DAMPER SHEET DUKE'94 Not Available Price: |
| 42 |
58030050700 |
CHAIN COVER BLACK '99 Price: Call Us |
| 43 |
0912060303 |
AH SCREW DIN0912-M 6X30 Price: Call Us |
| 45 |
58038017100 |
CU-SEAL RING DIN7603-22X27X2 Price: Call Us |
| 46 |
58038019100 |
OIL DRAIN PLUG M22X1,5 Price: Call Us |
| 47 |
58038022000 |
CU-seal ring DIN7603-12X18X1.5 Price: Call Us |
| 50 |
58538023000 |
OIL PRES.SPRING 5 BAR RED 2001 Price: Call Us |
| 51 |
58038028000 |
VALVE PISTON D=10MM Price: Call Us |
| 55 |
58430099200 |
GASKET SET LC4 2003 Price: Call Us |
| 60 |
0025060256 |
HH collar screw M6x25 TX30 This part replaces 0015060253. Price: Call Us |
| 61 |
0025060306 |
HH collar screw M6x30 TX30 This part replaces 0015060303. Price: Call Us |
| 62 |
0025060356 |
HH collar screw M6x35 TX30 This part replaces 0015060353. Price: Call Us |
| 63 |
0025060406 |
HH collar screw M6x40 TX30 This part replaces 0015060403. Price: Call Us |
| 66 |
0015060556 |
HH COLLAR SCR. M6X55 WS=8 10.9 This part replaces 0015060553. Price: Call Us |
