| Ref | Part Number | Description |
|---|
| 1 |
11200-ZVL-010 |
CVR, CRANKCASE Price: $396.76 |
| 2 |
11300-ZVP-000 |
CASE ASSY., OIL SEAL Price: $91.86 |
| 3 |
12000-ZVP-000 |
BLOCK ASSY., CYLN Price: $2,973.37 |
| 4 |
12155-ZV4-A01 |
METAL, ANODE Price: $14.94 |
| 5 |
12155-ZV5-010 |
METAL, ANODE Price: $13.06 |
| 6 |
12155-ZZ5-010 |
METAL, ANODE Price: $11.20 |
| 8 |
12164-ZY3-000 |
BOLT, SEALING (22MM) Price: $20.70 |
| 9 |
12214-ZV5-000 |
SEE PART DETAILS - PRI; WASHER, SEALING (22MM) Price: $4.00 |
| 10 |
15115-P8A-A01 |
SEE PART DETAILS - PRI; GASKET, OIL HOLE Price: $6.30 |
| 11 |
15140-P8A-A00 |
ORIFICE ASSY., OIL CONTROL Price: $18.30 |
| 12 |
15142-P8A-A00 |
O-RING (8.8X2.4) Price: $4.86 |
| 13 |
15150-P8A-A00 |
JOINT ASSY., OIL PIPE Price: $46.52 |
| 14 |
15152-ZVP-000 |
COLLAR, OIL PASSAGE Price: $7.08 |
| 15 |
15810-ZVL-003ZA |
VALVE ASSY., SPOOL *NH8* (DARK GRAY) Price: $353.76 |
| 16 |
15825-ZY3-003 |
FILTER ASSY., SPOOL VALVE Price: $28.02 |
| 17 |
19367-ZVP-000 |
COVER, W/J SIDE Price: $66.92 |
| 18 |
19368-ZVP-000 |
PKG, W/J SIDE COVER Price: $8.78 |
| 19 |
30530-R1A-A01 |
SENSOR, KNOCK Price: $236.04 |
| 20 |
32116-ZVP-000 |
BRACKET, HARN CLIP D Price: $5.18 |
| 21 |
35673-ZY3-003 |
SENSOR ASSY., WATER TEMPERATURE Price: $30.98 |
| 22 |
37260-ZVP-003 |
SENSOR, P-OIL Price: $136.76 |
| 23 |
37500-PNB-003 |
SENSOR ASSY., CRANK Price: $226.04 |
| 24 |
90001-MZ8-U40 |
BOLT, FLANGE (6X18) Price: $2.38 |
| 25 |
90003-ZX2-000 |
BOLT, FLANGE (5X20) Price: $2.58 |
| 26 |
90004-ZX2-000 |
BOLT, FLANGE (6X18) Price: $2.58 |
| 27 |
90008-ZVL-013 |
BOLT-WASHER (10X60) Price: $4.66 |
| 28 |
90009-ZVL-013 |
BOLT-WASHER (10X80) Price: $5.90 |
| 29 |
90014-RCA-A01 |
BOLT-WASHER (11X105) Price: $5.96 |
| 30 |
90017-ZZ5-M01 |
BOLT, FLANGE (6X16) Price: $1.70 |
| 31 |
90019-ZZ5-M01 |
BOLT, FLANGE (6X35) Price: $3.08 |
| 32 |
90020-ZVL-010 |
BOLT, FLANGE (8X50) Price: $1.70 |
| 33 |
90021-ZZ5-M01 |
BOLT, FLANGE (6X14) Price: $1.56 |
| 34 |
90030-ZZ5-M01 |
BOLT, FLANGE (6X22) Price: $1.80 |
| 35 |
90038-ZVL-010 |
BOLT, FLANGE (8X75) Price: $1.76 |
| 36 |
90054-ZY9-M01 |
BOLT, FLANGE (8X35) Price: $2.36 |
| 37 |
90081-ZZ5-M01 |
BOLT, SEALING (22MM) Price: $6.18 |
| 38 |
90715-PH7-000 |
PIN, DOWEL (13X37) Price: $7.74 |
| 39 |
91212-ZY3-003 |
OIL SEAL (41X66X8) Price: $18.08 |
| 40 |
91214-55C-E01 |
OIL SEAL (80X98X10) Price: $20.98 |
| 41 |
91307-PNA-003 |
O-RING (9.5X1.9) Price: $2.76 |
| 42 |
91308-P8A-A01 |
O-RING (18.3X3.5) Price: $8.00 |
| 43 |
91308-P3R-T01 |
SEE PART DETAILS - PRI; O-RING (26.2X2.4) (YAMADA SOMBOON) This part replaces 91308-PK1-003. Price: $2.72 |
| 44 |
91309-P8A-A01 |
O-RING (16.3X3.5) Price: $8.00 |
| 45 |
91319-PR3-003 |
O-RING (13X1.5) (ARAI) Price: $6.28 |
| 46 |
91321-P0X-003 |
O-RING (25X2.4) (NOK) Price: $5.76 |
| 47 |
91333-PNA-003 |
O-RING (15X1.9) Price: $4.14 |
| 48 |
93500-05020-4J |
SCREW, PAN (5X20) Price: $1.18 |
| 49 |
94301-06100 |
SEE PART DETAILS - PRI; PIN A, DOWEL (6X10) (Honda Code 0294256). Price: $2.82 |
| 50 |
12171-ZY3-305 |
WASHER, SEALING (22MM) Price: $3.66 |
