| Ref | Part Number | Description |
|---|
| 1 |
14321MCW000 |
SPROCKET, CAM (38T) Price: Call Us |
| 1 |
17877-ZV5-000 |
PLATE, REMOTE CONTROL CABLE Price: $10.80 |
| 2 |
14401MCW003 |
CHAIN, CAM (BORG WARNER)(132L) Price: Call Us |
| 2 |
24618-ZV5-000 |
PIVOT, SHIFT Price: $19.24 |
| 3 |
14405MCW000 |
ROTOR, CAM PULSE Price: Call Us |
| 3 |
35110-ZV5-003 |
KEY ASSY., COMBINATION SWITCH (35100-ZV5-003 ONLY) DUAL QTY = (4) (SINGLE) Price: $10.94 |
| 4 |
14510MCW003 |
TENSIONER, FR. CAM CHAIN Price: Call Us |
| 4 |
36182-ZV4-651 |
SEE PART DETAILS - PRI; WIRE, EMERGENCY (SINGLE) (DUAL) Price: $25.28 |
| 5 |
14515MCW003 |
TENSIONER, RR. CAM CHAIN Price: Call Us |
| 5 |
36187-ZV4-652 |
SEE PART DETAILS - PRI; CLIP, EMERGENCY LOCK This part replaces 36187-ZV4-651. Price: $5.72 |
| 6 |
14520MCW013 |
LIFTER ASSY., TENSIONER Price: Call Us |
| 6 |
40105-ZV5-000 |
GROMMET, CASE (LOWER) (A) Price: $17.30 |
| 7 |
14523MCW003 |
GASKET, TENSIONER HOLE Price: Call Us |
| 7 |
50212-ZW9-003 |
SEE PART DETAILS - PRI; BLOCK, FRICTION Price: $14.88 |
| 8 |
14524MBB000 |
CAP, LIFTER PAT Price: Call Us |
| 8 |
50218-ZW4-H00 |
PLATE, FRICTION Price: $59.14 |
| 9 |
14546MBW000 |
GUIDE COMP. B, CAM CHAIN Price: Call Us |
| 9 |
50219-ZW4-H00 |
LEVER, FRICTION Price: $11.28 |
| 10 |
14610MCW003 |
GUIDE A, CAM CHAIN Price: Call Us |
| 10 |
53116-ZW4-H11 |
BUSH, HANDLEBAR Price: $9.02 |
| 11 |
14626MBB000 |
COLLAR, 8MM Price: Call Us |
| 11 |
53130-ZW9-000 |
SEE PART DETAILS - PRI; GRIP ASSY., THROTTLE FRICTION Price: $29.72 |
| 12 |
53133-ZW9-000 |
PAD, THROTTLE FRICTION Price: $8.76 |
| 12 |
90004GHB600 |
BOLT, FLANGE, 6X10 (NSHF) Price: Call Us |
| 13 |
53130-ZW9-000 |
SEE PART DETAILS - PRI; GRIP ASSY., THROTTLE FRICTION Price: $29.72 |
| 13 |
90004GHB670 |
BOLT, FLANGE, 6X25 (NSHF) Price: Call Us |
| 14 |
53141-ZW4-H00 |
PIPE, GRIP Price: $32.34 |
| 14 |
90026MM8000 |
BOLT, UBS, 7X15 Price: Call Us |
| 15 |
53165-ZW9-000 |
RUBBER, GRIP Price: $15.34 |
| 15 |
90082HA0000 |
BOLT, FLANGE KNOCK, 7X10.5 Price: Call Us |
| 16 |
06530-ZW4-305ZA |
BRACKET KIT, STEERING *NH282MU* (OYSTER SILVER METALLIC-U) Price: $270.54 |
| 16 |
90124MCW000 |
BOLT, FLANGE, 6X15 Price: Call Us |
| 17 |
90101-ZW4-H00 |
BOLT, HEX. (12X80) Price: $22.48 |
| 17 |
90442397000 |
WASHER, SEALING, 6MM Price: Call Us |
| 18 |
90102-ZW9-000 |
BOLT, FLANGE (6X12) Use from Frame SN 1005249. Price: $2.90 |
| 18 |
957010601400 |
BOLT, FLANGE, 6X14 Price: Call Us |
| 19 |
90162-ZW9-000 |
BOLT, STUD (8X26) Price: $6.58 |
| 20 |
90303-ZW4-H00 |
NUT, HEX. (12MM) Price: $7.54 |
| 21 |
90305-ZW9-000 |
NUT, SELF-LOCK (8MM) Price: $6.72 |
| 22 |
90306-ZV5-003 |
NUT, SELF-LOCK (10MM) Price: $4.66 |
| 23 |
90504-921-010 |
WASHER, PLAIN (6MM) Use from Frame SN 4800713. Price: $1.74 |
| 24 |
90506-ZV1-000 |
WASHER, WAVE (14MM) Price: $3.34 |
| 25 |
90514-ZV4-000 |
WASHER (10MM) Price: $2.32 |
| 26 |
90514-921-000 |
WASHER (8MM) Price: $1.36 |
| 27 |
90517-ZW9-000 |
WASHER, NYLON (8MM) Price: $1.94 |
| 28 |
90552-ZV5-000 |
WASHER, PLAIN (12MM) Price: $6.40 |
| 29 |
90559-ZV5-000 |
WASHER, PLAIN (12MM) Price: $4.04 |
| 30 |
90765-ZV5-000 |
PIN, SPECIAL LOCK (6MM) Price: $2.44 |
| 31 |
91552-ZW4-H00 |
COLLAR, DISTANCE (12.2X23X16) Price: $10.80 |
| 32 |
94002-12490-0S |
NUT, HEX. (12MM) Price: $3.92 |
| 33 |
17910-ZW4-H01 |
CABLE, THROTTLE Price: $94.04 |
| 34 |
17917-ZW9-000 |
PIVOT, THROTTLE CABLE Price: $9.34 |
| 35 |
17931-ZW4-H02 |
ARM, THROTTLE Price: $39.20 |
| 36 |
24590-ZW4-H01 |
CABLE, SHIFT Price: $98.32 |
| 37 |
24614-ZW4-H02 |
SEE PART DETAILS - PRI; LEVER, SHIFT This part replaces 24614-ZW4-H01. Price: $57.96 |
| 38 |
24615-ZW4-H01 |
FRAME ASSY., SHIFT Price: $128.54 |
| 39 |
32533-ZW4-H01 |
TUBE (38.1X40) Price: $8.48 |
| 40 |
32534-ZW4-H01 |
TUBE (19X40) Price: $8.48 |
| 41 |
32538-ZW4-H01 |
CABLE ASSY., LONG HANDLE (A) Price: $198.20 |
| 42 |
32543-ZW4-H01 |
BAND (CONVEX CV-150) Price: $2.28 |
| 43 |
32544-ZW4-H01 |
BAND (CONVEX CV-200) Price: $2.28 |
| 44 |
32547-ZW4-H01 |
BAND (CONVEX) Price: $2.28 |
| 45 |
32548-ZW4-H01 |
COVER, WIRE Price: $17.02 |
| 46 |
32549-ZW4-H01 |
SCREW Price: $2.22 |
| 47 |
35100-ZW4-H02 |
SWITCH ASSY., COMBINATION Price: $120.14 |
| 48 |
35640-ZW4-H11 |
SWITCH ASSY., POWER TILT Price: $74.78 |
| 49 |
35643-ZW4-H02 |
GROMMET Price: $22.74 |
| 50 |
35645-ZW4-H01 |
HOLDER, SWITCH Price: $18.44 |
| 51 |
36180-ZV5-033 |
SEE PART DETAILS - PRI; SWITCH ASSY., EMERGENCY STOP Price: $77.86 |
| 52 |
37210-ZW1-702 |
LAMP ASSY., INDICATION (2-LED) DUAL QTY = (2) (SINGLE) Price: $163.44 |
| 53 |
06531-ZY9-305ZA |
HOUSING *NH282MU* (OYSTER SILVER METALLIC-U) Price: $186.94 |
| 54 |
53102-ZW4-H01 |
COVER (LOWER) Price: Call Us |
| 55 |
53103-ZW9-000 |
PIN, THROTTLE CABLE Price: $3.84 |
| 56 |
53104-ZW4-H02 |
BRACKET, CABLE Price: $7.86 |
| 57 |
53105-ZW4-H01 |
PLATE ASSY., LOCK Price: $49.08 |
| 58 |
53106-ZW4-H01 |
STOPPER Price: $15.58 |
| 59 |
53107-ZW4-H02 |
PLATE, GUIDE Price: $8.30 |
| 60 |
53108-ZW4-H01 |
GROMMET Price: $21.34 |
| 61 |
53109-ZW4-H02 |
CAP Price: $12.10 |
| 62 |
53112-ZW4-H02 |
GUIDE, SPRING Price: $30.16 |
| 63 |
53113-ZW4-H01 |
ACTUATOR Price: $7.02 |
| 64 |
53114-ZW4-H01 |
SPRING, COIL Price: $19.72 |
| 66 |
53116-ZW4-H01 |
ROLLER Price: $2.32 |
| 67 |
53117-ZW4-H01 |
SCREW (M5X14) Price: $1.16 |
| 68 |
53118-ZW4-H03 |
SEE PART DETAILS - PRI; GEAR, SHIFT Price: $34.48 |
| 69 |
53119-ZW4-H02 |
PLATE, BALL GUIDE Price: $13.10 |
| 70 |
53121-ZW4-H02 |
BRACKET Price: $16.80 |
| 71 |
90102-ZW4-H01 |
BOLT (M5X8) Price: $2.22 |
| 72 |
90103-ZW4-H02 |
SEE PART DETAILS - PRI; BOLT (M8X50) Price: $9.34 |
| 73 |
90104-ZW4-H01 |
BOLT (M5X12) Price: $2.22 |
| 74 |
90105-ZW4-H02 |
BOLT (M6X12) Price: $2.40 |
| 75 |
90106-ZW4-H01 |
BOLT (M5X12) Price: $2.10 |
| 76 |
90301-ZW4-H01 |
NUT, HEX. (5MM) Price: $2.22 |
| 77 |
90302-921-000 |
NUT, HEX. (16MM) DUAL QTY = (2) (SINGLE) Price: $5.62 |
| 78 |
90501-ZW4-H01 |
WASHER (5MM) Price: $2.22 |
| 79 |
90502-ZW4-H02 |
SEE PART DETAILS - PRI; WASHER (8MM) Price: $2.28 |
| 80 |
90503-ZW4-H01 |
WASHER (10MM) Price: $2.98 |
| 81 |
90504-ZW4-H01 |
WASHER (5MM) Price: $2.24 |
| 82 |
90651-ZW4-H01 |
E-RING Price: $6.68 |
| 83 |
90652-ZW4-H01 |
E-RING Price: $4.70 |
| 84 |
91051-ZW4-H01 |
BEARING Price: $4.50 |
| 85 |
91052-ZW4-H01 |
BEARING Price: $5.56 |
| 86 |
91408-ZJ1-810 |
TUBE, CORD (30MM) Price: $9.90 |
| 87 |
53130-ZW9-000 |
SEE PART DETAILS - PRI; GRIP ASSY., THROTTLE FRICTION Price: $29.72 |
| 93 |
06530-ZW4-305ZA |
BRACKET KIT, STEERING *NH282MU* (OYSTER SILVER METALLIC-U) Price: $270.54 |
