| Ref | Part Number | Description |
|---|
| 1 |
11204-KGF-900 |
SLEEVE, RR. BRAKE CAM Price: $10.04 |
| 2 |
21200-K97-T00 |
CASE COMP, TRANS Price: $57.80 |
| 3 |
21395-K97-T02 |
GASKET, TRANS CASE Price: $6.09 |
| 4 |
23411-K97-T01 |
SHAFT, DRIVE (15T) Price: $29.73 |
| 5 |
23421-K97-T01 |
COUNTERSHAFT (16T) Price: $29.18 |
| 6 |
23422-K97-T01 |
GEAR, COUNTER (55T) Price: $40.91 |
| 7 |
23430-K97-T01 |
GEAR, FINAL (43T) Price: $83.05 |
| 8 |
90452-KPH-C00 |
WASHER This part replaces 90452-KGH-900. Price: $3.02 |
| 9 |
90495-MN5-000 |
WASHER, SEALING (8MM) Price: $4.47 |
| 10 |
91004-KZR-601 |
BEARING, RADIAL BALL (6202) (NTN) Price: $10.75 |
| 11 |
91006-KZR-601 |
BEARING, RADIAL BALL (6201) (NTN) Price: $9.22 |
| 12 |
91009-KWN-901 |
BEARING, RADIAL BALL (6205UU) (NTN) Price: $9.35 |
| 13 |
91201-434-003 |
OIL SEAL (14X20X3.2) Price: $5.35 |
| 14 |
91204-K59-A11 |
OIL SEAL (34X52X7) Price: $2.78 |
| 15 |
94301-10120 |
PIN, DOWEL (10X12) Price: $2.58 |
| 16 |
95002-50000 |
CLIP, TUBE (C9) Price: $1.32 |
| 17 |
95005-50003-30M |
BULK HOSE, VACUUM (5X3000) (5X180) Price: $25.27 |
| 18 |
95701-08045-00 |
BOLT, FLANGE (8X45) Price: $1.67 |
