| Ref | Part Number | Description |
|---|
| 1 |
40510-K87-A01 |
CASE, DRIVE CHAIN Price: $14.58 |
| 2 |
40540-K0A-EB1 |
CHAIN, DRIVE Price: $127.22 |
| 2 |
40540-MKP-DN2 |
CHAIN, DRIVE Price: $294.80 |
| 3 |
40542-K2Y-A00 |
BOLT, CHAIN ADJ. Price: $1.93 |
| 4 |
40543-K87-A00 |
ADJUSTER, CHAIN Price: $17.78 |
| 5 |
40545-KYJ-902 |
MASTER LINK (DAIDO) Price: $17.51 |
| 5 |
40545-MKP-DN2 |
MASTER LINK Price: $25.38 |
| 6 |
40546-K87-A00 |
CAP, SWINGARM END Price: $15.02 |
| 7 |
52101-K87-H00 |
BOLT, SWINGARM PIVOT Price: $8.91 |
| 8 |
52105-K87-A00 |
COLLAR B, SWINGARM PIVOT Price: $5.67 |
| 9 |
52106-KYJ-900 |
COLLAR, PIVOT Price: $14.38 |
| 10 |
52109-K87-A00 |
BOLT, PIVOT ADJUSTING Price: $8.35 |
| 11 |
52141-K87-A00 |
COLLAR, PIVOT DISTANCE Price: $11.91 |
| 12 |
52170-K87-A00 |
SLIDER, CHAIN Price: $8.31 |
| 13 |
52200-K87-A00 |
SWINGARM SUB-ASSY., RR. Price: $761.98 |
| 14 |
90127-MKN-D50 |
SCREW, SPECIAL (6X14) Price: $1.53 |
| 15 |
90301-K87-A01 |
NUT, U (10MM) Price: $2.33 |
| 16 |
90302-K87-A00 |
NUT, LOCK (26X1.5) Price: $9.96 |
| 17 |
90305-KCJ-951 |
NUT, U (14MM) (FUJI SEIMITSU) Price: $6.71 |
| 18 |
90651-K87-A00 |
CIRCLIP (INNER) (20) Price: $1.78 |
| 19 |
90683-MBW-003 |
CLIP, BODY Price: $2.71 |
| 20 |
91071-MJ0-004 |
BEARING, NEEDLE (THOMPSON) This part replaces 91071-MJ0-003. Price: $44.65 |
| 21 |
91213-MB2-003 |
DUST SEAL (22X35X7) (ARAI) Price: $9.36 |
| 22 |
91283-ML7-003 |
DUST SEAL (22X29X4) (ARAI) Price: $7.44 |
| 23 |
94101-10700 |
WASHER, PLAIN (10MM) Price: $1.12 |
| 24 |
94520-35000 |
CIRCLIP (INNER) (35MM) Price: $2.03 |
