| Ref | Part Number | Description |
|---|
| 1 |
12010-K36-T00 |
HEAD ASSY. Price: $128.05 |
| 2 |
12204-KWN-P00 |
GUIDE, VALVE (OVER SIZE) Price: $12.18 |
| 3 |
12251-K97-T01 |
GASKET, CYL HD Price: $5.76 |
| 4 |
16222-MV4-300 |
NUT, SQUARE (5MM) (GQ51B C) Price: $2.45 |
| 5 |
17110-K97-T00 |
PIPE, INLET Price: $108.28 |
| 6 |
17112-KZY-700 |
INSULATOR, THROTTLE BODY Price: $13.55 |
| 7 |
17115-K77-V00 |
PIPE B, INLET Price: $12.44 |
| 8 |
17119-KZY-700 |
INSULATOR, IN. PIPE Price: $6.80 |
| 9 |
17120-K97-T00 |
STAY COMP Price: $8.25 |
| 10 |
17219-K97-T00 |
CLAMP TUBE BREATHER Price: $4.22 |
| 11 |
17255-KWN-900 |
BAND, INSULATOR Price: $2.02 |
| 12 |
31918-K97-T01 |
SPARK PLUG (MR8K-9) Price: $5.28 |
| 13 |
36532-K01-611 |
SENSOR, OXYGEN Price: $139.55 |
| 14 |
36533-KZR-601 |
WIRE, OXYGEN SENSOR Price: $43.33 |
| 15 |
37870-KZR-601 |
SENSOR ASSY., WATER TEMPERATURE Price: $10.75 |
| 16 |
90004-KGF-910 |
BOLT, STUD (7X17) Price: $2.42 |
| 17 |
90005-MEJ-000 |
BOLT, RECESSED (5X22) Price: $0.93 |
| 18 |
90483-KWN-900 |
WASHER (8MM) Price: $0.96 |
| 19 |
91301-KRJ-901 |
O-RING (29X2) Price: $3.65 |
| 20 |
91307-PLC-004 |
O-RING (9.5X1.9) (PANASONIC) Price: $3.90 |
| 21 |
93404-06012-00 |
BOLT-WASHER (6X12) Price: $1.70 |
| 22 |
94030-08280 |
NUT, HEX. (8MM) Price: $0.92 |
| 23 |
94301-10160 |
PIN, DOWEL (10X16) (Honda Code 0058206) Price: $2.58 |
| 24 |
94303-03050 |
PIN, DOWEL (3X5) Price: $2.35 |
| 25 |
95701-06014-00 |
BOLT, FLANGE (6X14) (Honda Code 2410884) Price: $1.15 |
| 26 |
95701-06040-00 |
BOLT, FLANGE (6X40) BOLT, FLANGE (6X45) Price: $1.97 |
| 27 |
95701-06095-00 |
BOLT, FLANGE (6X95) Price: $2.31 |
