| Ref | Part Number | Description |
|---|
| 5 |
40540603 |
Steel ball d3 Price: Call Us |
| 12 |
48600381 |
OUTER TUBE L=577MM D=54/60MM Not Available Price: |
| 15 |
48601009 |
Guide bushing 48x52x12 This part replaces 48600205. Price: Call Us |
| 17 |
S604800001000C1 |
Shaft seal SKF 48x58x11,4 black This part replaces 48600399. Price: Call Us |
| 18 |
48600070 |
Snap ring SB58x1,5 acc drawing Price: Call Us |
| 19 |
S604800000000C1 |
Dirtscarper SKF 48mm black This part replaces 48600400. Price: Call Us |
| 22 |
48601008 |
Guide bushing 47x49x20 This part replaces 48600204. Price: Call Us |
| 23 |
48601052 |
Fork inner tube 48x595 This part replaces 48600377. Price: Call Us |
| 24 |
48600380S1 |
Stop 14,4x32,1x200 cpl. This part replaces 48600380S. Price: Call Us |
| 30 |
48600092 |
ADJUSTMENT TUBE L=517MM Price: Call Us |
| 31 |
48600409 |
PISTON ROD D=14 L=551 M11X1 Price: Call Us |
| 33 |
48600189 |
Needle 6x42,6 rebound Price: Call Us |
| 36 |
48600113 |
Washer 32x42x2,5 plastic Price: Call Us |
| 38 |
91410011S |
SPRING 3,6N/MM SET Price: Call Us |
| 38 |
91410012S |
SPRING 3,8N/MM SET D=4,9MM Price: Call Us |
| 38 |
91410013S |
SPRING 4,0N/MM SET D=5,0MM Price: Call Us |
| 38 |
91410014S |
SPRING 4,2N/MM SET D=5,0MM Price: Call Us |
| 38 |
91410015S |
SPRING 4,4N/MM SET D=5,1MM Price: Call Us |
| 38 |
91410016S |
SPRING 4,6N/MM SET Price: Call Us |
| 38 |
91410017S |
SPRING 4,8N/MM SET Price: Call Us |
| 42 |
48600383S |
SCREW SLEEVE M29,3X1 L=90 CPL. Not Available Price: |
| 43 |
48600239 |
O-ring 8x1,25 NBR70 siliconize Price: Call Us |
| 44 |
48600403 |
Spring (15) 12-34,5 rebound Price: Call Us |
| 45 |
48600203 |
Tap 6x45 rebound Price: Call Us |
| 49 |
43570120 |
SHIM 8X18X0,10 This part replaces 48600068. Price: Call Us |
| 49 |
48600215 |
Shim 8x20x0,10 Price: Call Us |
| 49 |
48600216 |
Shim 8x22x0,10 Price: Call Us |
| 49 |
48600218 |
Shim 8X11X0,40 This part replaces 48600352. Price: Call Us |
| 49 |
48600357 |
Shim 8x11x0,10 Price: Call Us |
| 50 |
40540400 |
Shim 6x12x0,10 Price: Call Us |
| 50 |
40540401 |
Shim 6x14x0,10 Price: Call Us |
| 50 |
40540402 |
Shim 6x16x0,10 Price: Call Us |
| 50 |
40540403 |
Shim 6x18x0,10 Price: Call Us |
| 50 |
40540414 |
SHIM 6X16X0,25 Price: Call Us |
| 50 |
40540415 |
SHIM 6X18X0,25 Price: Call Us |
| 50 |
40540447 |
Shim 6x10x0,30 Price: Call Us |
| 50 |
40540450 |
Shim 6x9,5x0,30 Price: Call Us |
| 50 |
48600116 |
Shim 6x24x0,10 delta Price: Call Us |
| 55 |
40540486 |
Nut M6x0,5 h6,5 WAF10 rebound Price: Call Us |
| 58 |
48600081 |
TUBE 29,3X1X390 D=8,5MM Price: Call Us |
| 60 |
48600237S |
AXLE CLAMP L/S CPL. USD48 04 Price: Call Us |
| 61 |
48600861S |
Axle clamp right cpl. This part replaces 48600238S. Price: Call Us |
| 63 |
48600163 |
Nut valve M6x0,5 h6,5 WAF17 Price: Call Us |
| 64 |
48600202 |
Spring (8,5) l6,5 valve Price: Call Us |
| 69 |
48600586S3 |
Compression, cmpl. This part replaces 48600152S1. Price: Call Us |
| 74 |
48600586S3 |
Compression, cmpl. This part replaces 48600152. Price: Call Us |
| 75 |
48600190 |
Needle 10x11,6 compression Price: Call Us |
| 82 |
48600141 |
Rubber cap 35x10 NBR80 Price: Call Us |
| 83 |
48601166S1 |
Fork Fluid Viscosity 4.0 5L This part replaces 48600401S1. Price: Call Us |
| 85 |
48600075S |
PRE-LOAD ADJUSTER CPL.(1 PC.) Price: Call Us |
| 87 |
48600481 |
Cross countersunk head screw M This part replaces 48600076. Price: Call Us |
| 89 |
48600075 |
SCREW CAP M51X1,5 Not Available Price: |
| 90 |
48600073S |
ADAPTER ADJUST. KNOB + BUSHING Price: Call Us |
| 91 |
48600077 |
O-ring 26x2 NBR90 Price: Call Us |
| 93 |
48600072 |
Locking nut M25x1 LH h7 WAF32 Price: Call Us |
| 94 |
48600071 |
Carrier ring spring fork Price: Call Us |
| 98 |
T14034 |
Fuchs grease IPR (250g) This part replaces T511. Price: Call Us |
