| Ref | Part Number | Description |
|---|
| 1 |
06410-MGS-D30 |
DAMPER SET, WHEEL Price: $69.60 |
| 2 |
41201-MKW-D10 |
SPROCKET, FINAL DRIVEN (41T) Price: $75.18 |
| 3 |
42301-MGS-D31 |
AXLE, RR. WHEEL Price: $54.33 |
| 4 |
42311-MGS-D10 |
COLLAR, L. RR. WHEEL SIDE Price: $24.24 |
| 5 |
42312-MGS-D10 |
COLLAR, RR. BRAKE SIDE Price: $18.93 |
| 6 |
42515-MGS-D80 |
RING, RR. PULSER Price: $71.96 |
| 7 |
42615-MGS-D30 |
FLANGE SUB-ASSY., RR. DRIVEN Price: $296.87 |
| 8 |
42620-MGS-D10 |
COLLAR, RR. AXLE DISTANCE Price: $29.07 |
| 9 |
42625-MGS-D30 |
COLLAR B, RR. WHEEL DISTANCE Price: $23.60 |
| 10 |
42650-MKA-D81ZB |
WHEEL SUB-ASSY., RR. (TYPE1) Price: $1,023.58 |
| 11 |
42704-MER-D00 |
WEIGHT, BALANCE (10G) Price: $11.31 |
| 11 |
42705-MER-D00 |
WEIGHT, BALANCE (20G) Price: $19.89 |
| 11 |
42706-MER-D00 |
WEIGHT, BALANCE (30G) Price: $19.60 |
| 12 |
42711-MJL-D35 |
TIRE, RR. This part replaces 42711-MJL-D34. Price: $200.71 |
| 12 |
42711-MKW-D02 |
TIRE(160/60 ZR17) This part replaces 42711-MKW-D01. Price: $195.32 |
| 13 |
42755-MKA-D81 |
VALVE ASSY., CLAMP IN Price: $20.09 |
| 14 |
42758-MKA-D81 |
O-RING Price: $1.75 |
| 15 |
43251-MGS-D31 |
DISK, RR. BRAKE (SUNSTAR) Price: $388.56 |
| 16 |
90102-MAS-000 |
BOLT 2, STUD (12X25) Price: $5.04 |
| 17 |
90105-MV9-003 |
BOLT, DISK (8X24) (TSUKIBOSHI) This part replaces 90105-MBB-000. Price: $7.80 |
| 18 |
90302-MKT-D01 |
NUT U, FLANGE (12MM) Price: $4.22 |
| 19 |
90306-MCS-G01 |
NUT, U (18MM) Price: $8.56 |
| 20 |
90401-MAS-000 |
WASHER (20X31.5X2) Price: $4.02 |
| 21 |
90559-MKW-D00 |
WASHER, RR. SWINGARM Price: $6.15 |
| 22 |
91051-MGS-D31 |
BEARING, ANGULAR BALL (22X50X15) Price: $46.16 |
| 23 |
91053-MGS-D31 |
BEARING, RADIAL BALL (6204UU) Price: $15.65 |
| 24 |
91251-MGS-D31 |
DUST SEAL (30X50X7) Price: $15.58 |
| 25 |
91253-MAE-003 |
DUST SEAL (30X47X7.5) Price: $19.33 |
