| Ref | Part Number | Description |
|---|
| 1 |
12281-MFY-A00 |
FIN, CYLINDER HEAD (RR. R.) Price: $203.96 |
| 2 |
12291-MFY-A00 |
FIN, CYLINDER HEAD (RR. L.) Price: $209.84 |
| 3 |
12320-MEA-670 |
COVER, RR. CYLINDER HEAD Price: $346.44 |
| 4 |
12341-MEA-670 |
COVER, IN. TAPPET ADJUSTING HOLE Price: $18.15 |
| 5 |
12361-383-000 |
CAP, TAPPET ADJUSTING HOLE Price: $8.07 |
| 6 |
12380-MFR-670 |
COVER, R. RR. OVER HEAD Price: $106.44 |
| 7 |
12390-MFR-A00 |
COVER, L. RR. OVER HEAD Price: $76.78 |
| 8 |
12392-HC4-005 |
GASKET, TAPPET COVER (KOYO) Price: $4.93 |
| 9 |
17622-GB7-900 |
RUBBER, CUSHION Price: $6.02 |
| 10 |
18601-MCH-003 |
VALVE, REED Price: $32.82 |
| 11 |
18612-MCH-000 |
COVER, REED VALVE Price: $24.25 |
| 12 |
19041-611-003 |
RUBBER, BUSHING (DENSO) Price: $44.78 |
| 13 |
83501-MG7-000 |
GROMMET, SIDE COVER (16MM ATTACHES PROTECTOR SET, SIDE TO COVER, PILLION STEP) Price: $2.98 |
| 14 |
83551-GE2-000 |
GROMMET, AIR CLEANER HOUSING Price: $7.07 |
| 15 |
90004-GHB-650 |
BOLT, FLANGE (6X20) (NSHF) Price: $2.24 |
| 16 |
90006-GHB-670 |
BOLT, FLANGE (6X25) (NSHF) Price: $2.05 |
| 17 |
90012-896-750 |
BOLT, FLANGE (5X14) Price: $1.58 |
| 18 |
90015-MG8-000 |
BOLT, FLANGE (8X150) Price: $7.62 |
| 19 |
90201-HA0-000 |
NUT, FLANGE CAP (10MM) Price: $8.09 |
| 20 |
90403-ML4-611 |
WASHER (10MM) Price: $7.09 |
| 21 |
90441-706-000 |
WASHER, SEALING (6MM) Price: $1.46 |
| 22 |
90441-ME9-000 |
WASHER, SEALING (8MM) Price: $2.98 |
| 23 |
90443-107-000 |
NUT, CAP (8MM) Price: $3.29 |
| 24 |
90581-831-650 |
WASHER (18MM) This part replaces 90482-567-000. Price: $2.34 |
| 25 |
90502-KGB-610 |
COLLAR, HEAD SIDE COVER Price: $2.42 |
| 26 |
91303-KK3-830 |
O-RING (35X3) (ARAI) SEAL, VALVE STEM (NOK) Price: $3.62 |
| 27 |
94301-14200 |
PIN A, DOWEL (14X20) Price: $2.58 |
