| Ref | Part Number | Description |
|---|
| 1 |
73451G01 |
PLASTIC BED ASSY, 40" Price: $1,352.52 |
| 2 |
CNAS |
COMPONENT NOT AVAILABLE SEPARATELY Price: Call Us |
| 3 |
73454G01 |
TAILGATE PIVOT SHAFT Price: $29.99 |
| 4 |
73460G01 |
SHOULDER BOLT, 0.875" DIA X 3/4" Price: $9.99 |
| 5 |
73455G01 |
TAILGATE CABLE Price: $56.99 |
| 6 |
N/S |
NON-SERVICEABLE PART Price: Call Us |
| 7 |
16705G2 |
PAN HEAD PHILLIPS SCREW, 1/4-20 X 5/8 Price: $2.99 |
| 8 |
73449G01 |
EXTRUSION CHANNEL Price: $73.99 |
| 9 |
16816G5 |
RATCHET RIVET, 0.187X 0.550 Price: $1.99 |
| 11 |
00415G2 |
HEX HEAD BOLT, 1/4-20 X 1 1/4 Price: $2.99 |
| 12 |
74821G01 |
BED LOAD DECAL, 500 LBS Price: $13.99 |
| 13 |
71055G01 |
RIVET, 3/16 X .38 Price: $1.99 |
| 14 |
70113G01 |
ADJUSTABLE RUBBER BUMPER Price: $19.99 |
| 15 |
11027G1 |
FLANGED LOCK NUT, 5/16"-18 Price: $0.99 |
| 18 |
74962G01 |
BED LATCH Price: $185.99 |
| 19 |
71538G01 |
TORSION SPRING, 1/2" DIA X 1" Price: $9.99 |
| 20 |
71099G02 |
LATCH PLATE, KEEPER Not Available Price: |
| 21 |
71477G02 |
LATCH RETAINER BRACKET Price: $29.65 |
| 22 |
01118G01 |
HEX HEAD BOLT, 1/4-20 X 5/8 Price: $2.99 |
| 24 |
71704G01 |
HANDLE GRIP Price: $10.99 |
| 25 |
617804 |
SVC-DECAL,BBB TAILGATE Price: $19.68 |
| 27 |
71570G01 |
ACETAL BUSHING Price: $7.99 |
| 28 |
71571G01 |
CLEVIS PIN, 1/2" X 5 1/4" Price: $5.99 |
| 29 |
00571G5 |
FLAT WASHER, WIDE, 1/2" Price: $1.99 |
| 30 |
21683G1 |
COTTER PIN, 15/32" X 2 1/16" Price: $2.99 |
| 31 |
624030 |
FLANGED BUSHING, IGUS Price: $1.99 |
| 32 |
71569G02 |
GAS SPRING CHANNEL Price: $39.99 |
| 33 |
01118G01 |
HEX HEAD BOLT, 1/4-20 X 5/8 Price: $2.99 |
| 34 |
N/S |
NON-SERVICEABLE PART Price: Call Us |
| 35 |
00642G7 |
FLAT WASHER, 1/4" Price: $2.99 |
| 36 |
652444G03 |
BED BUMPER BRACKET This part replaces 74947G01. Price: $38.99 |
| 37 |
71537G02 |
GAS SPRING Price: $91.99 |
| 38 |
14443G10 |
CLEVIS PIN,.50 X 3.00 Price: $14.99 |
| 39 |
14443G12 |
PIN CLEVIS 1/2 X 2.22 Price: $8.99 |
| 40 |
21683G1 |
COTTER PIN, 15/32" X 2 1/16" Price: $2.99 |
| 41 |
00642G7 |
FLAT WASHER, 1/4" Price: $2.99 |
| 42 |
01118G01 |
HEX HEAD BOLT, 1/4-20 X 5/8 Price: $2.99 |
| 43 |
71547G02 |
CHANNEL OUTRIGGER Price: $370.99 |
| 44 |
72339G02 |
HEAT SHIELD PLASTIC BED RH Price: $74.95 |
| 45 |
74164G01 |
ELECTRIC DUMP KIT Price: Call Us |
| 46 |
27612G02 |
ELECTRIC ACTUATOR, 12V-1500# Price: $1,256.99 |
| 47 |
27680G01 |
TOGGLE SWITCH, ELECTRIC DUMP Price: $36.63 |
| 48 |
27447G01 |
TOGGLE GUARD ASSY Price: $96.88 |
| 49 |
74165G02 |
CIRCUIT BREAKER MNTG BRACKET Price: $11.69 |
| 50 |
00150G4 |
SLOTTED SCREW, #10-24 X 1/2 Price: $2.18 |
| 51 |
00565G5 |
LOCK WASHER, #10 Price: $0.99 |
| 52 |
21320G3 |
CIRCUIT BREAKER, 30A, 12V Price: $37.99 |
| 53 |
17618G1 |
NYLON CLAMP, 8" Price: $1.99 |
| 54 |
00526G3 |
HEX NUT, #10-24 Price: $0.99 |
| 55 |
10570G9 |
DOMED RIVET,1/8, PULL-THRU Price: $1.99 |
| 56 |
25976G14 |
RED WIRE ASSY, #14GA Price: $1.01 |
| 57 |
71489G01 |
DECAL, READ INSTRUCTIONS Price: $57.10 |
| 59 |
27613G01 |
SPACER-.75O.D. X .50I.D. Price: $34.99 |
