FRAME COVER (GSX-S1000YAL9 E03)
Parts (19)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 47110-04K00 | COVER,FRAME FRONT RH Price: $72.24 |
| 3 | 44572-13G00 | FASTENER (33X25X2.6) Price: $13.67 |
| 5 | 47210-04K00 | COVER,FRAME FRONT LH Price: $55.87 |
| 7 | 44572-13G00 | FASTENER (33X25X2.6) Price: $13.67 |
| 9 | 09320-06504 | CUSHION Price: $6.04 |
| 10 | 09409-10314 | CLIP Price: $2.41 |
| 11 | 47131-04K00 | COVER,FRAME RR LWR RH Price: $26.47 |
| 12 | 47231-04K00 | COVER,FRAME RR LWR LH Price: $26.97 |
| 19 | 47313-04K01 | TAPE,FRAME COVER RH Price: $12.02 |
| 20 | 47314-04K01 | TAPE,FRAME COVER LH Price: $13.76 |
| 21 | 09320-08028 | CUSHION (8X26X7) Price: $3.70 |
| 22 | 02142-1520B | SCREW Price: $2.73 |
| 23 | 09159-05019 | NUT (M5) Price: $8.69 |
| 24 | 09148-05047 | NUT (M5) Price: $2.37 |
| 26 | 09180-06283 | SPACER (6.5X10X7) Price: $2.30 |
| 27 | 09136-06105 | SCREW (6X20) Price: $2.41 |
| 30 | 47312-04K00 | TAPE,FRAME COVER CTR Price: $13.76 |
| 31 | 03541-0512B | SCREW Price: $2.15 |
| 32 | 09148-05047 | NUT (M5) Price: $2.37 |
