| Ref | Part Number | Description |
|---|
| 1 |
BG4-F1171-01-00 |
BOX,TOOL Price: $137.99 |
| 2 |
B4J-H339E-00-00 |
INSU., 1 Price: $41.99 |
| 3 |
90183-062A1-00 |
NUT, SPRING Price: $2.20 |
| 4 |
90480-01558-00 |
GROMMET Price: $4.65 |
| 5 |
90109-068A5-00 |
BOLT Price: $8.49 |
| 6 |
2MB-F143A-00-00 |
CAP Price: $1.95 |
| 7 |
371-27114-00-00 |
STOPPER, MAIN STAND Price: $8.49 |
| 8 |
BG4-F471S-00-00 |
BELT, BODY HOLDER Price: $9.49 |
| 9 |
BG4-K8193-21-00 |
PANEL, REAR FENDER 3 Price: $372.99 |
| 10 |
90110-06090-00 |
BOLT, HEXAGON SOCKET HEAD Price: $5.49 |
| 11 |
90109-06202-00 |
BOLT Price: $3.10 |
| 12 |
90183-062A1-00 |
NUT, SPRING Price: $2.20 |
| 13 |
BG4-K8194-21-00 |
PANEL, REAR FENDER 4 Price: $372.99 |
| 14 |
90110-06090-00 |
BOLT, HEXAGON SOCKET HEAD Price: $5.49 |
| 15 |
90109-06202-00 |
BOLT Price: $3.10 |
| 16 |
90183-062A1-00 |
NUT, SPRING Price: $2.20 |
| 17 |
BAR-K810N-10-00 |
REAR STORAGE LID C Price: $309.99 |
| 18 |
BG4-F389F-02-00 |
HANDLE, LATCH Price: $83.99 |
| 19 |
92017-06010-00 |
BOLT, BUTTON HEAD Price: $5.49 |
| 20 |
BG4-F8478-00-00 |
ROD Price: $115.99 |
| 22 |
BG4-F331G-00-00 |
COVER Price: $32.99 |
| 23 |
90111-06181-00 |
BOLT,HEX. SOCKET BUT Price: $1.50 |
| 24 |
1XD-F463F-00-00 |
HINGE 2 Price: $48.99 |
| 25 |
90149-06846-00 |
SCREW Price: $1.55 |
| 26 |
BG4-F16A0-00-00 |
LOCK ASSY Price: $36.99 |
| 27 |
BG4-F16B0-00-00 |
LOCK ASSY 2 Price: $36.99 |
| 28 |
95D32-06016-00 |
BLOT, FLANGE DEEP RE Price: $0.50 |
| 29 |
5UG-K7195-10-00 |
HOLDER, CABLE Price: $33.99 |
| 30 |
90109-06171-00 |
BOLT Price: $9.49 |
| 31 |
BG4-F8416-10-00 |
DAMPER 2 Price: $1.90 |
| 32 |
90109-06202-00 |
BOLT Price: $3.10 |
| 33 |
BG4-F4441-00-00 |
BOLT, STUD Price: $8.49 |
