| Ref | Part Number | Description |
|---|
| 1 |
08L55EWL820 |
TOP BOX 45L PEARL CONCOURS BLACK Price: Call Us |
| 1 |
16075-935-006 |
O-RING Price: $1.50 |
| 2 |
08L52MCWLOCK |
KEY LOCK SET - PANNIERS/TOPBOX Price: Call Us |
| 2 |
16900-881-000 |
SEE PART DETAILS - SUP; JOINT A, FUEL Price: $62.82 |
| 2 |
16900-881-010 |
SEE PART DETAILS - PRI; JOINT A, FUEL Price: $60.38 |
| 3 |
08L55MCW80004 |
TOP BOX REFLECTOR Price: Call Us |
| 3 |
16951-935-006 |
JOINT A, FUEL CONSENT Price: $47.46 |
| 4 |
08L55MY580022 |
STOPPER CORD, ASSY Price: Call Us |
| 4 |
16952-935-016 |
JOINT B, FUEL CONSENT Price: $15.30 |
| 5 |
08L55MY580021 |
RUBBER BAND, COMP Price: Call Us |
| 5 |
16953-935-000 |
ABSORBER, FUEL Price: $4.46 |
| 6 |
08L55MCW80006 |
PANEL, RIGHT Price: Call Us |
| 6 |
16962-865-010 |
RING, PETCOCK SEAL Price: $4.10 |
| 7 |
08L55MCW80007 |
PANEL, LEFT Price: Call Us |
| 7 |
17500-881-020ZA |
TANK, FUEL *R8* (BRIGHT RED) Price: Call Us |
| 8 |
08L55MCW80010 |
TOP BOX MARK Price: Call Us |
| 8 |
17570-921-000 |
TANK, OIL Price: $18.24 |
| 9 |
08L55MCW80019 |
LOCK BRACKET ASSY Price: Call Us |
| 9 |
17572-801-810 |
CAP, SUB-TANK (INNER) Price: Call Us |
| 10 |
08L55MCW80008 |
SIDE REFLECTOR Price: Call Us |
| 10 |
17573-801-810 |
CAP, SUB-TANK Price: Call Us |
| 11 |
08L55MCW80005 |
SHEET, TOP BOX REFLECTOR Price: Call Us |
| 11 |
17583-881-000 |
FILTER, FUEL Price: $8.98 |
| 12 |
08P11MCW800 |
TOP BOX MAT Price: Call Us |
| 12 |
17611-935-000 |
TUBE (INNER) Price: $5.88 |
| 14 |
17620-881-053 |
SEE PART DETAILS - PRI; CAP, FUEL FILLER Price: $40.94 |
| 15 |
04104-ZW9-010 |
SEE PART DETAILS - PRI; CONNECTOR SET, FUEL This part replaces 17650-ZV4-005. Price: $71.86 |
| 16 |
17661-921-010 |
SEE PART DETAILS - PRI; PRIMER BULB This part replaces 17661-921-000. Price: $17.80 |
| 17 |
17670-921-000 |
VALVE, IN. Price: $8.78 |
| 18 |
17680-ZV4-000 |
VALVE, OUTLET Price: $16.62 |
| 19 |
17690-881-000 |
BOX, TOOL Price: Call Us |
| 20 |
17698-921-000 |
LATCH, TOOL BOX Price: Call Us |
| 21 |
17699-921-000 |
STOPPER, LATCH Price: Call Us |
| 22 |
04101-ZW9-660 |
SEE PART DETAILS - SUP; TUBE ASSY., FUEL Price: Call Us |
| 22 |
04101-ZW9-661 |
TUBE ASSY., FUEL This part replaces 17700-ZV4-800. Price: $163.52 |
| 23 |
17701-881-000 |
TUBE, FUEL LONG Price: $46.20 |
| 24 |
17702-ZV4-000 |
TUBE, FUEL SHORT Price: $13.36 |
| 25 |
17703-921-010 |
SEE PART DETAILS - PRI; BAND, TUBE CLIP (20MM) This part replaces 17703-921-000. Price: $4.84 |
| 26 |
17704-ZV4-000 |
SEE PART DETAILS - SUP; BAND, TUBE CLIP (12.5MM) Price: $2.00 |
| 26 |
17704-ZV4-010 |
SEE PART DETAILS - PRI; BAND, TUBE CLIP (12.5MM) Price: $2.98 |
| 27 |
17704-921-000 |
BAND, TUBE CLIP (11MM) Price: $5.16 |
| 28 |
17800-ZV1-611 |
METER ASSY., FUEL Price: $24.86 |
| 29 |
17803-GC3-003 |
GASKET, FUEL METER Price: $11.52 |
| 33 |
90120-881-010 |
SEE PART DETAILS - SUP; BOLT, FLANGE (6X16) Price: Call Us |
| 34 |
90445-700-000 |
GASKET, FIBER (6MM) Price: $1.64 |
| 35 |
90540-881-000 |
GASKET, FIBER (5MM) Price: $1.82 |
