| Ref | Part Number | Description |
|---|
| 1 |
18291-GE2-920 |
GASKET, EX. PIPE Price: $8.13 |
| 2 |
18291-KR1-680 |
GASKET A, EX. PIPE Price: $10.53 |
| 3 |
18293-MCA-A20 |
RUBBER, PROTECTOR GASKET Price: $2.35 |
| 4 |
18300-K2E-A11 |
MUFFLER, EX. Price: $958.40 |
| 5 |
18306-K2E-A00 |
CAP, TAIL Price: $178.04 |
| 6 |
18317-K2E-A00 |
ARRESTER, SPARK Price: $254.24 |
| 7 |
18325-K2E-T00 |
COVER, EX. PIPE Price: $79.20 |
| 8 |
18345-MBT-610 |
RUBBER, PROTECTOR MOUNTING Price: $2.49 |
| 9 |
18356-K2E-T00 |
COVER, MUFFLER Price: $199.80 |
| 10 |
18421-K26-B00 |
RUBBER, MUFFLER MOUNTING Price: $0.67 |
| 11 |
18422-K26-900 |
COLLAR, MUFFLER MOUNTING Price: $5.47 |
| 12 |
96001-06010-07 |
BOLT, FLANGE (6X10) This part replaces 90101-KCE-000. Price: $1.70 |
| 13 |
90106-GBB-710 |
SCREW, PAN (6X10) Price: $1.44 |
| 14 |
90113-GFP-B00 |
SCREW, PAN (6X12) Price: $4.49 |
| 15 |
90165-K2E-T00 |
BOLT, ADAPTER (8MM) Price: $8.05 |
| 16 |
90301-KWB-600 |
NUT, FLANGE (8MM) Price: $1.00 |
| 17 |
90443-KTM-970 |
NUT, CAP (8MM) Price: $0.87 |
| 18 |
94103-08700 |
WASHER, PLAIN (8MM) Price: $0.98 |
