| Ref | Part Number | Description |
|---|
| 1 |
640873 |
Needs Description Price: Call Us |
| 2 |
624934 |
PLUG,PLASTIC,1X2 RECTANGLE Price: Call Us |
| 3 |
641289 |
FLANGED HEX HEAD BOLT, 3/8-16 X 1 Price: $3.99 |
| 4 |
N/S |
NON-SERVICEABLE PART Price: Call Us |
| 8 |
632991G01 |
Needs Description Price: Call Us |
| 9 |
16705G1 |
TRUSS HEAD SCREW, 1/4-20X1 Price: $2.99 |
| 10 |
23726G4 |
SPACER, 5/16 Price: $1.99 |
| 11 |
14390G4 |
LOCK NUT,1/4"-20 Price: $1.99 |
| 12 |
632991G02 |
Needs Description Price: Call Us |
| 15 |
637455G01 |
WRAP,PANEL,SIDE,FRT SEAT,LH Price: $195.57 |
| 16 |
71055G01 |
RIVET, 3/16 X .38 Price: $1.99 |
| 17 |
N/S |
NON-SERVICEABLE PART Price: Call Us |
| 18 |
637455G02 |
WRAP,PANEL,SIDE,FRT SEAT,RH Price: $195.57 |
| 19 |
637453 |
WRAP,PANEL,REAR KICK Price: $428.41 |
| 20 |
637454G01 |
WRAP,PANEL,FRONT,FRONT SEAT Not Available Price: |
| 21 |
10570G10 |
DOMED RIVET, SS, 5/32' X 9/16" Price: $1.99 |
| 24 |
638697 |
BRACKET,SEAT RETENTION Price: $9.74 |
| 25 |
638668 |
SEAT RETENTION GROMMET Price: $5.99 |
| 26 |
N/S |
NON-SERVICEABLE PART Price: Call Us |
| 27 |
14390G10 |
LOCK NUT, #10-24 Price: $1.99 |
| 30 |
70441G03 |
WELDMENT,SEAT FRAME,TXT ELECTR Price: $42.81 |
| 31 |
00438G8 |
HEX HEAD BOLT, 5/16-18 X 1 Price: $2.99 |
| 32 |
00559G8 |
FLAT WASHER, 5/16" Price: $0.99 |
| 33 |
11098G6 |
LOCK NUT, 5/16"-18 Price: $2.99 |
| 34 |
00715G2 |
HEX WASHER HEAD BOLT, 5/16-18 X 0.8 Price: $1.99 |
| 36 |
638047G0XX |
Needs Description Price: Call Us |
| 37 |
638049G0XX |
Needs Description Price: Call Us |
| 39 |
641344G01 |
Needs Description Price: Call Us |
| 40 |
641344G02 |
Needs Description Price: Call Us |
| 41 |
00664G7 |
LOCK WASHER, 0.255" X 0.263" Price: $0.99 |
| 42 |
16705G1 |
TRUSS HEAD SCREW, 1/4-20X1 Price: $2.99 |
| 43 |
641536 |
SCREW,QUARTER TURN,28MM-ASSEMBLY Price: $15.89 |
| 44 |
641509 |
Needs Description Price: Call Us |
| 45 |
10570G10 |
DOMED RIVET, SS, 5/32' X 9/16" Price: $1.99 |
| 46 |
635654 |
CLIP-ON,RECEPTACLE,QUARTER TURN Price: $3.86 |
