| Ref | Part Number | Description |
|---|
| 1 |
5820300154490 |
FRAME CPL. ADVENTURE 2003 Price: Call Us |
| 2 |
5840300234490 |
SUBFRAME CPL. STEEL SILVER 00 Price: Call Us |
| 4 |
58303002090 |
PLUG 12 X 17 MM Price: Call Us |
| 5 |
5810300420090 |
FOOTRESTBRACK. REAR R/S SILVER Not Available Price: |
| 5 |
5840304800090 |
FOOTRESTBRACK. REAR L/S 04 Not Available This part replaces 5810300320090. Price: |
| 7 |
0934080003 |
Hexagon nut DIN934 M8 Price: Call Us |
| 10 |
59001037000 |
SPECIAL SCREW M8X26 WS=10 Price: Call Us |
| 11 |
58003012000 |
SPACER ROLLER 10,3X20X22 Price: Call Us |
| 12 |
71001012100 |
PVC CAP D=22MM Price: Call Us |
| 13 |
58307015000 |
TANK SUPPORT '93 Not Available Price: |
| 14 |
58303055000 |
ENGINE SUPPORT AGW '94 Not Available Price: |
| 16 |
58403013000 |
ENGINE BRAC.SCREW M10X110 WS13 Not Available Price: |
| 17 |
55530044000 |
Collar nut M10-SW13 ZnNi This part replaces 54630044000. Price: Call Us |
| 18 |
0025080166 |
HH COLLAR SCREW M8X16 TX40 This part replaces 49109481052. Price: Call Us |
| 19 |
54310086200 |
Self locking nut M8 10.9 Price: Call Us |
| 20 |
58403002370 |
BATTERY BOX 03 Not Available Price: |
| 21 |
0025060106 |
HH collar screw M6x10 TX30 This part replaces 0015060103. Price: Call Us |
| 22 |
0021060003 |
Washer DIN9021-A 6.4 Price: Call Us |
| 24 |
0797060003 |
TOOTH LOCK WASH. DIN6797-A 6,4 Price: Call Us |
| 25 |
0934060003 |
Hex. nut DIN 934 M6 Price: Call Us |
| 26 |
58403002010 |
RUBBER GROMMET 20X15-M6X8-(2) Price: Call Us |
| 30 |
0931100603 |
HH SCREW DIN0931-M10X60 Not Available Price: |
| 31 |
0982100003 |
SELF LOCK.NUT DIN0982-M10 HIGH Price: Call Us |
| 32 |
58403014000 |
ENGINE BRAC.SCREW M10X160 WS13 Price: Call Us |
| 36 |
55007016001 |
PVC-HOSE 7X10 PER METER Price: Call Us |
| 37 |
50303089000 |
ANGLE PIECE '97 Price: Call Us |
| 40 |
5830304000090 |
FOOTREST L/S SILVER '99 Price: Call Us |
| 41 |
5460314000090 |
FOOT REST R/S SILVER '98 Not Available Price: |
| 42 |
58303041000 |
FOOTREST SPRING L/S '93 Price: Call Us |
| 43 |
54603041000 |
FOOTREST SPRING L/S R/S Price: Call Us |
| 44 |
58303044000 |
BOLT FOR FOOTREST Price: Call Us |
| 45 |
54803044000 |
PIN FOR FOOT PED 51.5X9.8 MM This part replaces 54603044000. Price: Call Us |
| 47 |
0094032250 |
PIN DIN 0094-3.2X25 NIRO This part replaces 0094032253. Price: Call Us |
| 50 |
58303050044 |
FOOTREST REAR L/S CPL. '95 Price: Call Us |
| 50 |
58303150044 |
FOOT REST REAR R/S CPL.'95 Price: Call Us |
| 51 |
58303045044 |
FOOTREST RUBBER CPL. '94 Price: Call Us |
| 52 |
58303051000 |
FOOTREST RUBBER L/SR/S DUKE95 Price: Call Us |
| 53 |
58403060000 |
CHAIN ROLL 12X29X22,5 '98 Price: Call Us |
| 55 |
58403060065 |
BUSH CHAIN ROLL 8X12X23 '98 Price: Call Us |
| 56 |
0797080003 |
TOOTHLOCK WASHER DIN6797-J 8,4 Price: Call Us |
| 58 |
0985060003 |
Self lock. nut DIN985-M6-A2 Price: Call Us |
| 59 |
51103053000 |
CHAIN SLIDING PIECE BELOW '97 Price: Call Us |
| 60 |
51103053051 |
BUSHING 8,2X10X20 Price: Call Us |
| 61 |
54403135000 |
PLASTIC CAP SFL10 Price: Call Us |
| 68 |
36003014000 |
LOCK WASHER 8MM Price: Call Us |
| 70 |
0025080306 |
HH collar screw M8x30 This part replaces 0015080303. Price: Call Us |
| 71 |
0015080453 |
HH COLLAR SCREW M 8X45 WS=10 Price: Call Us |
| 72 |
0910160153 |
PLUG DIN0910-M16X1,5 Not Available Price: |
| 73 |
0603162220 |
CU-SEAL RING 16X22X2 Price: Call Us |
| 74 |
0019080206S |
FLAT HEAD SCREW M. ISA45 M8X20 This part replaces 54610052000. Price: Call Us |
| 76 |
0019080266S |
COUNTER-SUNK SCREW ISA45 M8X26 This part replaces 54510052100. Price: Call Us |
| 77 |
0984060103 |
AH SCREW DIN7984-M 6X10 Price: Call Us |
| 80 |
58303010000 |
COVER OIL FILTER '94 Not Available Price: |
| 81 |
0024060156 |
HH collar screw M6x15 TX30 This part replaces 0014060153. Price: Call Us |
| 82 |
0024060106 |
HH COLLAR SCREW M6X10 TX30 This part replaces 0014060103. Price: Call Us |
| 90 |
58412099044 |
SKID PLATE LIMITED CPL. 97 Price: Call Us |
| 91 |
0024060106 |
HH COLLAR SCREW M6X10 TX30 This part replaces 0014060103. Price: Call Us |
| 93 |
58003012200 |
ENGINE PROTECTOR BRACKET '97 Price: Call Us |
| 94 |
0024060156 |
HH collar screw M6x15 TX30 This part replaces 0014060153. Price: Call Us |
