| Ref | Part Number | Description |
|---|
| 1 |
21222-17K00 |
WASHER,PRI DRIVEN GEAR THR Price: $21.68 |
| 3 |
21253-01H10 |
SPACER,OIL PUMP DRIVE SPROCKE Price: $44.78 |
| 4 |
09263-35015 |
BEARING (35X40X26.8) Price: $29.36 |
| 5 |
09263-35045 |
BEARING (35X40X12) Price: $24.58 |
| 6 |
21411-17K00 |
HUB,CLUTCH SLEEVE Price: $174.75 |
| 7 |
21413-17K00 |
SPRING,CLUTCH Price: $7.81 |
| 8 |
21415-17K00 |
SEAT,CLUTCH SPRING Price: $13.15 |
| 9 |
21414-17K00 |
PLATE,STOPPER Price: $17.10 |
| 15 |
21462-17K00 |
DISC,CLUTCH PRESSURE Price: $101.93 |
| 16 |
21471-02F20 |
SEAT,WAVE WASHER Price: $18.76 |
| 17 |
21472-02F20 |
WASHER,CLUTCH PLATE WAVE Price: $26.96 |
| 18 |
21482-17K00 |
BOLT,CLUTCH SPRING Price: $3.84 |
| 19 |
09160-25056 |
WASHER (25X50X2.5) Price: $14.34 |
| 20 |
09159-24010 |
NUT Price: $16.09 |
| 21 |
09164-24008 |
WASHER (24.2X35X2.7) Price: $4.83 |
| 22 |
09181-25223 |
SHIM (25X38X1) Price: $3.91 |
| 23 |
23110-27A00 |
ROD,CLUTCH (L:161) Price: $26.79 |
| 24 |
23111-26D00 |
ROD,CLUTCH PUSH,L (L:132.5) Price: $19.61 |
| 25 |
23121-41G30 |
PIECE, CLUTCH PUSH Price: $61.69 |
| 26 |
23122-41G00 |
CAMSHAFT,CLUTCH RELEASE Price: $61.46 |
| 27 |
23123-41G00 |
CAP,CLUTCH PUSH ROD Price: $13.51 |
| 28 |
23125-41G00 |
SPRING,CLUTCH RELEASE RETURN Price: $4.01 |
| 29 |
23271-41G50 |
ARM,CLUTCH RELEASE Price: $58.29 |
| 30 |
09103-06527 |
BOLT (6X20) Price: $2.01 |
| 31 |
09134-06015 |
SCREW (6X73) Price: $8.39 |
| 32 |
09160-10020 |
WASHER (10.5X24X1.0) Price: $2.18 |
| 33 |
09160-15045 |
WASHER (15.5X28X1) Price: $4.75 |
| 34 |
09263-10014 |
BEARING (10X14X10) Price: $16.47 |
| 35 |
09263-12027 |
BEARING (12X18X12) Price: $8.90 |
| 36 |
09263-15003 |
BEARING (15X28X2) Price: $10.10 |
| 37 |
09282-10012 |
SEAL,OIL (10X20X6) Price: $9.72 |
| 38 |
09283-06013 |
SEAL,OIL Price: $16.02 |
| 39 |
09285-10004 |
SEAL,OIL (10X17X5) Price: $4.10 |
