| Ref | Part Number | Description |
|---|
| 1 |
8CR-17660-30-00 |
SECONDARY FIXED SHEAVE COMP. Price: $587.99 |
| 2 |
8AV-17688-10-00 |
SHOE, RAMP Price: $35.99 |
| 3 |
8BV-17656-00-00 |
STOPPER, HOLDER Price: $24.99 |
| 4 |
98907-06016-00 |
SCREW, BIND This part replaces 90154-06062-00. Price: $10.49 |
| 5 |
8BU-17670-30-00 |
SECONDARY SLIDING SHEAVE Price: $259.99 |
| 6 |
90384-38243-00 |
BUSH, BIMETAL FORMED Price: $69.99 |
| 7 |
95617-08630-00 |
BOLT, STUD Price: $5.49 |
| 8 |
90105-06734-00 |
BOLT, FLANGE Price: $3.80 |
| 10 |
90179-08655-00 |
NUT Price: $11.49 |
| 12 |
90384-38243-00 |
BUSH, BIMETAL FORMED Price: $69.99 |
| 14 |
8HF-17681-01-00 |
SHAFT, SECONDARY Price: $584.99 |
| 15 |
8FN-47631-00-00 |
HOUSING, BEARING Price: $125.99 |
| 16 |
93306-30579-00 |
BEARING Price: $72.99 |
| 17 |
99009-62500-00 |
CIRCLIP Price: $9.49 |
| 18 |
99009-25400-00 |
CIRCLIP Price: $9.49 |
| 19 |
90149-08034-00 |
SCREW Price: $2.25 |
| 22 |
90387-14019-00 |
COLLAR Price: $33.99 |
| 23 |
90201-14022-00 |
WASHER, PLATE This part replaces 90201-141A3-00. Price: $6.49 |
