CRANKSHAFT - PISTON
Parts (19)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 2N4-11400-00-00 | CRANKSHAFT ASSEMBLY Price: $371.99 |
| 2 | 1W1-11412-01-00 | CRANK 1 Price: $282.99 |
| 3 | 1W1-11422-01-00 | CRANK 2 Price: $144.99 |
| 4 | 25V-11651-00-00 | ROD, CONNECTING 1 Price: $108.99 |
| 5 | 3M5-11681-00-00 | PIN, CRANK 1 Price: $26.99 |
| 6 | 90209-22248-00 | WASHER, SPECIAL SHAPE Price: $20.99 |
| 7 | 93310-422L0-00 | BEARING Price: $60.99 |
| 8 | 3X3-11631-00-97 | PISTON STD Price: $124.99 |
| 9 | 3X3-11610-00-00 | PISTON RINGSET STD Price: $46.99 |
| 10 | 93310-216L2-00 | BEARING, CYLINDRICAL Price: $36.99 |
| 11 | 137-11633-10-00 | PIN, PISTON This part replaces 137-11633-00-00. Price: $30.99 |
| 12 | 93450-17044-00 | CIRCLIP Price: $9.49 |
| 13 | 93306-20529-00 | BEARING (B6205C4) Price: $44.99 |
| 14 | 93306-30421-00 | BEARING (B6304C3) Price: $71.99 |
| 15 | 93103-25125-00 | OIL SEAL, SW-TYPE Price: $29.99 |
| 16 | 93103-28011-00 | OIL SEAL, SW-TYPE (93103-28100) Price: $16.49 |
| 17 | 93210-180A6-00 | O-RING Price: $8.49 |
| 18 | 90387-20488-00 | COLLAR Price: $27.99 |
| 19 | 90280-03017-00 | KEY, WOODRUFF This part replaces 90280-03004-00. Price: $8.49 |
