| Ref | Part Number | Description |
|---|
| 1 |
34158U5901 |
Fork HQV 450 FC 2021 US Price: $2,823.33 |
| 2 |
0025080506 |
HH collar screw M8x50 TX40 Price: $3.62 |
| 3 |
0025080256 |
HH collar screw M8x25 Price: $2.41 |
| 4 |
0025080406 |
HH COLLAR SCREW M8X40 TX40 Price: $4.83 |
| 5 |
0015080256S |
HH COLLAR SCREW M8X25 WS=10 Price: $3.62 |
| 6 |
0032100356S |
AH-COLLAR SCREW M10X35 ISA45 Price: $4.99 |
| 7 |
83001040000 |
RUBBER BUSH Price: $6.15 |
| 8 |
0770025035 |
O-RING 25X3,55 NBR70 05 Price: $1.99 |
| 9 |
0017060206 |
SCREW F. PLASTIC K60X20AL SW6 Price: $3.99 |
| 10 |
79001037034 |
HANDLEBAR SUPPORT LOWER PART Price: $71.71 |
| 11 |
81312920100 |
Hourmeter This part replaces 81312920050. Price: $65.99 |
| 12 |
0912040163 |
AH SCREW DIN0912-M 4X16 Price: $2.99 |
| 32 |
7900103202230 |
LOWER TRIPLE CLAMP CPL. 16 Price: $494.66 |
| 34 |
7910103402230 |
Top triple clamp X=22 mm 2019 Price: $263.22 |
| 36 |
72001036000 |
COLLAR SCREW M20X1,5 WS17 AL Price: $13.52 |
| 38 |
79001038000 |
HANDLEBAR CLAMP 28MM Price: $81.61 |
| 39 |
79001039036 |
HANDLEBAR SUPPORT D28MM-H36MM Price: $38.16 |
| 81 |
54201081100 |
TAPERED ROLLER BEARING CPL. 06 Price: $60.05 |
| 82 |
77701084000 |
O-RING SUPPORT W. SEALING LIP Price: $22.76 |
| 84 |
54601184000 |
STEARING HEAD GASKET TOP Price: $8.35 |
| 85 |
25001085100HA |
CLAMP FOR BRAKEHOSE Price: $2.99 |
| 86 |
78101086000 |
STEERING HEAD COVER Price: $7.14 |
| 91 |
59001092050 |
SPECIAL SCREW M6X12,5 WS=8 Price: $2.99 |
| 92 |
25001094100HAB |
Fork protection kit TC/FCáá 2022 Price: $60.60 |
