| Ref | Part Number | Description |
|---|
| 1 |
32145-MKC-L80 |
SUB-HARNESS, SPEAKER Price: $35.22 |
| 2 |
39011-MLJ-A00 |
AUDIO SET (NOT AVAILABLE) Price: $5,226.93 |
| 3 |
39115-MKC-A01 |
CORD ASSY., USB Price: $58.11 |
| 4 |
39115-TK6-003 |
CLIP, USB CONNECTOR HOLDER (A) (L. SIDE ONLY) Price: $1.23 |
| 5 |
39150-MKC-A01 |
ANTENNA ASSY., RADIO Price: $226.29 |
| 6 |
39151-MKC-A01 |
SUB-HARNESS, RADIO ANTENNA GROUND Price: $8.82 |
| 7 |
39160-MKC-A01 |
SPEAKER UNIT (NOT AVAILABLE) Price: $235.78 |
| 8 |
39190-MKC-L81 |
CORD ASSY., USB Price: $53.84 |
| 9 |
39213-MKC-A01 |
ANTENNA ASSY., BLUETOOTH (RR) Price: $99.18 |
| 10 |
39221-MCA-S51 |
SCREW, PAN (3X6) Price: $1.91 |
| 11 |
39230-MKC-A01 |
ANTENNA ASSY., GPS Price: $246.64 |
| 12 |
64181-MKC-A00 |
BOX, R. SPEAKER Price: $79.25 |
| 13 |
64183-MKC-A00 |
PLATE, R. SPEAKER BOX Price: $33.91 |
| 14 |
64184-MKC-A00 |
CUSHION, SPEAKER Price: $20.20 |
| 15 |
64191-MKC-A00 |
BOX, L. SPEAKER Price: $75.80 |
| 16 |
64193-MKC-A00 |
PLATE, L. SPEAKER BOX Price: $33.91 |
| 17 |
77302-124-000 |
WASHER, SEAT MOUNTING Price: $4.05 |
| 18 |
90111-162-000 |
BOLT, FLANGE (6MM) Price: $3.29 |
| 19 |
90111-KW3-003 |
NUT, COWL SETTING (5MM) Price: $5.67 |
| 20 |
90503-MKC-A00 |
COLLAR (6.3X14) Price: $4.82 |
| 21 |
90505-MKC-A00 |
RUBBER, AUDIO MOUNT Price: $4.75 |
| 22 |
90650-KV6-003 |
BAND, WIRE (Honda Code 2687788) Price: $3.91 |
| 23 |
90661-SJ8-003 |
GROMMET, SCREW (5MM) Price: $3.35 |
| 24 |
93892-05020-07 |
SCREW-WASHER (5X20) Price: $0.98 |
| 25 |
93901-25280 |
SCREW, TAPPING (5X12) Price: $0.95 |
| 26 |
93903-25210 |
SCREW, TAPPING (5X12) Price: $0.87 |
| 27 |
93903-25310 |
SCREW, TAPPING (5X16) Price: $0.75 |
| 28 |
94050-06000 |
NUT, FLANGE (6MM) Price: $0.68 |
| 29 |
95701-06010-00 |
BOLT, FLANGE (6X10) BOLT, FLANGE (6X12) Price: $1.32 |
| 30 |
95701-06012-08 |
BOLT, FLANGE (6X12) Price: $1.70 |
