| Ref | Part Number | Description |
|---|
| 1 |
18150-K2Y-J40 |
PIPE, EX. Price: $496.67 |
| 2 |
18155-K87-A00 |
PLATE, EX. Price: $5.16 |
| 3 |
18291-MEB-670 |
GASKET, EX. PIPE Price: $6.18 |
| 4 |
18293-MCA-A20 |
RUBBER, PROTECTOR GASKET Price: $2.35 |
| 5 |
18310-K2Y-J40 |
MUFFLER Price: $550.18 |
| 6 |
18345-MBT-610 |
RUBBER, PROTECTOR MOUNTING Price: $2.49 |
| 7 |
18355-K87-A00 |
COVER, MUFFLER Price: $31.36 |
| 8 |
18371-K2Y-J00 |
BAND, MUFFLER Price: $19.55 |
| 9 |
18391-MGP-D60 |
GASKET, MUFFLER Price: $33.87 |
| 10 |
18421-MB0-000 |
RUBBER, MUFFLER MOUNTING Price: $7.96 |
| 11 |
18422-MAL-600 |
COLLAR, MUFFLER MOUNTING This part replaces 18422-KAF-700. Price: $7.44 |
| 12 |
36533-K2Y-J41 |
SENSOR Price: $93.45 |
| 13 |
53781-SE0-952 |
CLIP, RETURN HOSE Price: $7.93 |
| 14 |
90103-KCM-620 |
BOLT, FLANGE (8X35) Price: $1.80 |
| 15 |
90115-K87-A00 |
SCREW, PAN (6X12) Price: $1.25 |
| 16 |
90163-GHB-730 |
BOLT, FLANGE (8X50) Price: $0.91 |
| 17 |
90304-KPH-700 |
NUT, HEX. CAP (8MM) Price: $1.95 |
| 18 |
94050-08070 |
NUT, FLANGE (8MM) Price: $1.71 |
| 19 |
94103-08700 |
WASHER, PLAIN (8MM) Price: $0.98 |
