| Ref | Part Number | Description |
|---|
| 1 |
24271-743-000 |
SPRING, BALL SETTING Price: $3.00 |
| 2 |
35340-MGS-D31 |
SWITCH ASSY., FR. STOP Price: $22.42 |
| 3 |
43450-MKW-D11 |
CABLE, PARKING BRAKE Price: $52.76 |
| 4 |
43455-MKW-D10 |
CLAMP, PARKING CABLE Price: $9.60 |
| 5 |
43456-MGS-D70 |
GUIDE, PARKING BRAKE Price: $7.82 |
| 6 |
47111-MKW-D80 |
HOLDER (UPPER) Price: $51.73 |
| 7 |
47117-MGS-D50 |
COVER, HOLDER Price: $4.36 |
| 8 |
47152-MGS-D51 |
LEVER, PARKING TOP Price: $12.67 |
| 9 |
47154-MGE-D00 |
SPRING, SWITCH Price: $9.71 |
| 10 |
47155-MGE-D00 |
SPRING, PLUNGER Price: $4.55 |
| 11 |
47156-MGE-D00 |
CAP, HOLDER (LOWER) Price: $2.64 |
| 12 |
47200-MKW-D10 |
LEVER ASSY., PARKING Price: $396.93 |
| 13 |
47210-MGS-D51 |
LEVER, PARKING Price: $51.09 |
| 14 |
90401-430-000 |
WASHER (10.2MM) Price: $1.96 |
| 15 |
90515-GN5-910 |
WASHER, PLAIN (4X8) Price: $1.42 |
| 16 |
90651-KV6-003 |
BAND, WIRE (165MM) (BLACK) Price: $3.65 |
| 17 |
90690-GHB-641 |
CLIP, CABLE (10MM) CLIP, CABLE (8MM) Price: $2.49 |
| 18 |
90801-SB0-000 |
PLUG, CHANGE REINFORCEMENT Price: $3.97 |
| 19 |
93500-05016-0G |
SCREW, PAN (5X16) SCREW, PAN (4X20) Price: $0.95 |
| 20 |
93892-04014-07 |
SCREW-WASHER (4X14) Price: $1.03 |
| 21 |
94305-30223 |
PIN, SPRING (3X22) Price: $1.36 |
| 22 |
94305-30283 |
PIN, SPRING (3X28) (NOT AVAILABLE) Price: $1.58 |
| 23 |
94540-09018 |
E-RING (9MM) (NOT AVAILABLE) Price: $4.03 |
| 24 |
96001-06014-00 |
BOLT, FLANGE (6X14) Price: $1.88 |
