EVAP SYSTEM (DL1000XAL9 E33)
Parts (14)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 44434-31J01 | HOSE, TANK & BREATHER VALVE Price: $23.17 |
| 2 | 09401-11413 | CLIP (ID:11,H:8) Price: $2.72 |
| 3 | 18572-31J00 | BRACKET, SURGE HOSE Price: $9.98 |
| 4 | 01550-0612A | BOLT Price: $2.37 |
| 5 | 17210-15H10 | CANISTER Price: $305.51 |
| 6 | 09251-07003 | CAP (OD:11.5) Price: $2.68 |
| 7 | 18571-31J10 | CUSHION, CANISTER Price: $18.31 |
| 8 | 09401-12404 | CLIP (ID:12) Price: $2.85 |
| 9 | 09367-06009 | JOINT Price: $2.80 |
| 10 | 18561-31JB0 | HOSE, CSTR PURGE NO.1 Price: $31.98 |
| 11 | 18561-31J10 | HOSE, CSTR PURGE NO.2 Price: $41.53 |
| 12 | 18561-31J20 | HOSE, CSTR PURGE NO.3 Price: $42.26 |
| 13 | 18563-31JA0 | HOSE, CSTR SURGE NO.1 Price: $31.98 |
| 14 | 18563-31JB0 | HOSE, CSTR SURGE NO.2 Price: $36.17 |
