| Ref | Part Number | Description |
|---|
| 1 |
B4X-13610-01-00 |
REED VALVE ASSY Price: $319.99 |
| 2 |
B4X-13621-00-00 |
GASKET, VALVE SEAT Price: $6.49 |
| 3 |
B4X-13565-00-00 |
JOINT, CARBURETOR Price: $49.99 |
| 4 |
95E32-06025-00 |
BOLT, FLANGE DEEP RECESS Price: $0.50 |
| 5 |
90450-54007-00 |
HOSE CLAMP ASSY Price: $16.49 |
| 6 |
90450-70002-00 |
HOSE CLAMP ASSY Price: $24.99 |
| 7 |
BCR-14401-00-00 |
AIR CLEANER CASE A Price: $113.99 |
| 8 |
90183-060A7-00 |
NUT, SPRING Price: $9.49 |
| 9 |
90387-06069-00 |
COLLAR Price: $9.49 |
| 10 |
1C3-14453-11-00 |
JOINT, AIR CLEANER 1 Price: $73.99 |
| 11 |
5NY-14459-00-00 |
HOLDER, GUIDE Price: $41.99 |
| 12 |
5NY-14455-20-00 |
BAND Price: $44.99 |
| 13 |
5NY-14442-00-00 |
SPACER Price: $25.99 |
| 14 |
BCR-1449E-00-00 |
COVER, AIR CLEANER Price: $31.99 |
| 15 |
90267-32196-00 |
RIVET, BLIND Price: $1.15 |
| 16 |
90201-03313-00 |
WASHER, PLATE Price: $10.49 |
| 17 |
4XM-14451-01-00 |
ELEMENT, AIR CLEANER Price: $41.99 |
| 18 |
90209-06096-00 |
WASHER Price: $10.49 |
| 19 |
90122-06005-00 |
BOLT, WING Price: $13.49 |
| 20 |
BCR-14458-00-00 |
GUIDE Price: $17.49 |
| 21 |
90480-10M28-00 |
GROMMET Price: $3.55 |
