| Ref | Part Number | Description |
|---|
| 1 |
1022256 |
WELD-SEAT FRAME Price: $239.99 |
| 2 |
2693407 |
ASM-SEAT BACK,BLK/TTM,BLK ST Price: $379.99 |
| 3 |
2693409 |
ASM-SEAT BTM,BLK/TTM,BLK ST Price: $244.99 |
| 4 |
7515177 |
SCREW-1/4-20x3/4 BH TRX, GR5-Z Price: $3.99 |
| 7 |
5258647 |
PLATE-LATCH,SEAT Price: $7.99 |
| 8 |
5437121 |
HANDLE-SEAT BASE LATCH Price: $5.99 |
| 9 |
7082653 |
SPRING-LATCH,SEAT Price: $44.99 |
| 10 |
7517610 |
SCREW-M6X1.00X40-HX/FL-YD Price: $1.99 |
| 11 |
7546703 |
NUT-6MM X 1 NYLOK-Z Price: $1.49 |
| 12 |
5270634 |
BRACKET, SEAT, SLIDER, ADJUSTABLE PLATE Price: $17.99 |
| 13 |
7518994 |
SCR-RHCARM6X1.0X20 8.8 ZOD Price: $3.99 |
| 14 |
7547339 |
NUT-M6X1.0, FLG-NYLOC-OLIVE D Price: $1.49 |
| 15 |
5257974 |
BRACKET, SEAT SLIDER MOUNTING PLATE Price: $79.99 |
| 16 |
5260733 |
BRACKET, SEAT SLIDER LEVER Price: $34.99 |
| 17 |
7044099 |
SPRING Price: $6.99 |
| 18 |
7518786 |
SCR-SH-M6X1.0X9.5 12.9 ZY3 Price: $2.99 |
| 19 |
7518897 |
BOLT, SHOULDER Price: $1.99 |
| 20 |
5340145 |
TUBE, SPACER Price: $6.99 |
| 21 |
7519296 |
SCR-1/4-20X1-BH-TRX-GR5-Z Price: $1.99 |
| 22 |
7552801 |
WASHER-1/4 SPRING LOCK-Y Price: $1.99 |
| 23 |
7555859 |
WASHER-FL .281X.750X.062-Y Price: $1.49 |
| 24 |
5415501-070 |
PAD-SEAT BASE,RZR,MP Price: $49.99 |
| 25 |
5140211 |
SLEEVE-SHLD,15.5OD,10 OD,6.5ID Price: $4.99 |
