| Ref | Part Number | Description |
|---|
| 1 |
630752 |
DECAL,BBB ON OFF Price: $4.79 |
| 5 |
618358 |
ROCKER PANEL, DRIVER SIDE Price: $92.99 |
| 6 |
618359 |
ROCKER PANEL, PASS. SIDE Price: $92.99 |
| 7 |
16705G1 |
TRUSS HEAD SCREW, 1/4-20X1 Price: $2.99 |
| 8 |
15058G6 |
ALUMINUM RIVET (BLACK), 3/16"X0.95L Price: $3.99 |
| 11 |
628642 |
PANEL,KEYSWITCH,FNR Price: $28.88 |
| 12 |
71055G01 |
RIVET, 3/16 X .38 Price: $1.99 |
| 15 |
630049GXX |
SEAT WRAP PANEL (see COLOR CODE in HOW TO USE section) Price: Call Us |
| 16 |
10570G10 |
DOMED RIVET, SS, 5/32' X 9/16" Price: $1.99 |
| 18 |
609047G1XX |
LOWE SIDE PANEL, DRIVER SIDE Price: Call Us 609047G1XX LOWE |
| 20 |
N/S |
NON-SERVICEABLE PART Price: Call Us |
| 21 |
71055G01 |
RIVET, 3/16 X .38 Price: $1.99 |
| 23 |
629087 |
COVER,BATTERY Not Available Price: |
| 26 |
71609G01 |
SEAT HINGE PLATE Price: $7.99 |
| 30 |
70441G01 |
SEAT FRAME Price: $152.99 |
| 31 |
00715G2 |
HEX WASHER HEAD BOLT, 5/16-18 X 0.8 Price: $1.99 |
| 32 |
00468G6 |
HEX HEAD BOLT Price: Call Us |
| 33 |
00559G8 |
FLAT WASHER, 5/16" Price: $0.99 |
| 34 |
11098G6 |
LOCK NUT, 5/16"-18 Price: $2.99 |
| 36 |
652254G03 |
BATTERY RACK This part replaces 70046G02. Price: $210.99 |
| 37 |
70200G01 |
TRUSS HEAD TORX SCREW, 3/8-16X3/4 Price: $3.99 |
| 38 |
00715G2 |
HEX WASHER HEAD BOLT, 5/16-18 X 0.8 Price: $1.99 |
| 40 |
652443G103 |
BATTERY TRAY BRACKET, DRIVER SIDE This part replaces 629688G01. Price: $39.99 |
| 41 |
629688G02 |
BRKT,TRAY,BATTERY,RH Price: $51.53 |
| 42 |
00715G2 |
HEX WASHER HEAD BOLT, 5/16-18 X 0.8 Price: $1.99 |
| 45 |
630289 |
OBS-DECAL,INSTINCT,BBB Not Available Price: |
| 46 |
630290 |
OBS-DECAL,RECOIL,BBB Not Available Price: |
