| Ref | Part Number | Description |
|---|
| 1 |
06450-HL1-A01 |
SEAL SET, PISTON Price: $12.53 |
| 2 |
06451-HL3-A00 |
PAD SET, L. FR. Price: $85.34 |
| 3 |
06452-HL3-A00 |
PAD SET, R. FR. Price: $85.34 |
| 4 |
43234-S04-003 |
COVER, DUST Price: $5.88 |
| 5 |
43235-S84-A51 |
PIN A Price: $11.42 |
| 6 |
43262-S84-A51 |
PIN B Price: $6.33 |
| 7 |
43352-SM4-951 |
SCREW, BLEEDER Price: $9.37 |
| 8 |
43353-SD5-003 |
CAP, BLEEDER SCREW Price: $6.68 |
| 9 |
45018-S3A-013 |
CALIPER SUB-ASSY., R. FR. (PART APPLIES TO LEFT SIDE FR SXS500) Price: $492.51 |
| 10 |
45019-S3A-013 |
CALIPER SUB-ASSY., L. FR. (PART APPLIES TO RIGHT SIDE FR SXS500) Price: $492.51 |
| 11 |
45216-S5A-003 |
PISTON Price: $73.32 |
| 12 |
45220-S2K-013 |
BRACKET, CALIPER Price: $94.51 |
| 13 |
45228-SF4-023 |
SHIM, BRAKE PAD Price: $9.96 |
| 14 |
45237-S2K-003 |
RETAINER Price: $7.35 |
| 15 |
45240-SC2-003 |
BOLT, FLANGE (8X22) Price: $10.38 |
